Volkswagen Corrado (1993 year). Manual - part 192





SYSTEM WIRING DIAGRAMS

SYSTEM WIRING DIAGRAMS

         TRANSMISSION

SYSTEM WIRING DIAGRAMS

END OF ARTICLE

TRANSMISSION REMOVAL & INSTALLATION - A/T

         TRANSMISSION SERVICING
         Volkswagen Transmission Removal & Installation - Automatic

         Corrado SLC, Passat

         REMOVAL & INSTALLATION

         REMOVAL

         1) Obtain radio code. Disconnect negative battery cable.
Remove air ducts to brake caliper and engine air intake. Disconnect
speedometer cable from transaxle.
         2) Remove upper transaxle-to-engine bolts. Disconnect and
plug transaxle cooler lines. Support engine from above. Remove
starter. Disconnect accelerator and selector cables from transaxle.
         3) Remove left transaxle mount and support. Remove electrical
wiring from transaxle. Remove lower bolts on front mount and remove
mount.
         4) Place mating marks on axle shaft flanges. Remove left and
right axle shaft flange bolts. Disconnect right strut-to-spindle
bolts. Remove right side axle. Reconnect strut. Remove protective
plate from transaxle.
         5) Remove torque converter-to-drive plate bolts. Slightly
lower engine assembly. Support transaxle with jack. Remove lower
transaxle-to-engine mounting bolts. Lower transaxle.

         INSTALLATION

         To install, reverse removal procedure. Adjust accelerator and
selector cables if necessary. Use NEW self-locking nuts. Tighten bolts
to specification. See TORQUE SPECIFICATIONS.

         TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS TABLE

ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ

Applications                                  Ft. Lbs. (N.m)

Axle Shaft Nut  .................................  195 (265)
Axle Shaft-To-Flange Bolts  .......................  33 (45)
Engine Mount Bolts  ...............................  33 (45)
Strut-To-Spindle Bolts  ...........................  70 (95)
Torque Converter-To-Drive Plate Bolts  ............  44 (60)
Transaxle-To-Engine
  M10 Bolts  ......................................  44 (60)
  M12 Bolts  ......................................  59 (80)

ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ

END OF ARTICLE
