Volkswagen New Beetle. Manual - part 998





z

Turn crankshaft to TDC marking before installing cylinder head.

z

Turn crankshaft against engine direction of rotation until all pistons are approximately equally placed
below TDC.

z

Note cylinder head gasket identification.

z

Part No. = arrow -1-

z

Control code = arrow -2- (not significant!)

z

Hole(s) = arrow -3-

Fig. 101: Identifying Cylinder Head Gasket Control Code And Hole
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Charge pressure hoses and line connections must be free of oil and
grease before reinstalling.

NOTE:

z

If the cylinder head gasket or the cylinder head are replaced,
use a new cylinder head gasket with same number of holes as
the old gasket.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

Install cylinder head sealant.

z

Observe center sleeves (arrows) in cylinder block.

Fig. 102: Locating Center Sleeves In Cylinder Block
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Observe head gasket installation position, identification "above" or Part No. must show to cylinder
head.

z

Install cylinder head and cylinder head bolts, and tighten by hand.

z

Tighten cylinder head in four stages in sequence shown as follows:

z

Tighten initially with torque wrench:

Stage I = 40 N.m

Stage II = 60 N.m

z

Turn further with normal spanner:

Stage III = 1/4 turn (90°)

Stage IV = 1/4 turn (90°)

z

If components of the crankshaft system have been replaced the
new cylinder head gasket must be re-selected by measuring the
piston projection in TDC. See PISTON PROJECTION AT TDC,
CHECKING .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 103: Cylinder Head Bolt Tightening Sequence
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

After tightening cylinder head, turn camshaft hub so cam lobes for cylinder No. 1 point evenly upward
(arrows).

Install in reverse order.

NOTE:

z

It is not necessary to retighten cylinder head bolts after completing
the repairs.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 104: Cam Lobes For Cylinder No. 1 Pointing Upward
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Observe tightening sequence for securing bolts when installing oil return line. See PART 3:
REMOVING AND INSTALLING OIL RETURN LINE TO TURBOCHARGER
 .

z

Before installing toothed belt, turn crankshaft in direction of engine rotation to TDC and lock in position
using crankshaft stop T10050.

z

Perform a road test and check DTC memory. See ENGINE CONTROL MODULE (DTC) MEMORY,
READING AND ERASING
 .

Compression pressure, checking

Special tools and equipment

CAUTION: When performing repair work, especially due to the confined

conditions in the engine compartment, pay attention to the following:

z

Route all types of hoses/lines (e.g. for fuel, hydraulics, EVAP
system, coolant, refrigerant, brake fluid and vacuum) as well as
electrical wiring so that the original positions are restored.

z

Ensure sufficient clearance to all moving or hot components.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
