Volkswagen New Beetle. Manual - part 969





z

For right coolant fan

14. Retaining clip

z

Check if seated securely

15. Fan ring

16. Coolant fan - V7-

z

Checking, See COOLANT FAN, CHECKING

z

Removing and installing, See RADIATOR, REMOVING AND INSTALLING

17. Retainer

z

For coolant fan connector

18. Lower coolant hose

z

Secured to radiator with retaining clip

z

Coolant hose connection diagram, See COOLANT HOSE CONNECTION DIAGRAM

z

Check if seated securely

19. Coolant Fan Control (FC) thermal switch -F18-, 35 N.m

z

For electric fan

z

Switching temperatures: 1. stage on: 92...97°C, off: 84...91°C; 2. stage on: 99...105 C, off: 91...98°
C

20. Retainer

z

For bottom of radiator

21. Retainer

z

For top of radiator

z

Observe installed position



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)



Fig. 2: Exploded View Of Body Side Cooling System Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

COOLING SYSTEM COMPONENTS -ENGINE SIDE, REMOVING AND INSTALLING



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)



1. Heating system heat exchanger

2. Connector

z

4-pin

z

Gold plated contacts for ECT sensor - G62-

3. Engine Coolant Temperature (ECT) sensor -G62-

z

For engine control module

z

With ECT sensor -G2-

z

Gold plated contacts for ECT sensor -G62-

z

Release pressure in cooling system if necessary before removing components

4. Connector

z

2-pin

z

Only for engine code AEG until Model Year 1999

z

Only vehicles with air conditioner with 4-pin A/C Pressure Switch -F129-

5. A/C cut-out thermal switch -F163-

z

Only for engine code AEG until Model Year 1999

z

Only vehicles with air conditioner with 4-pin A/C Pressure Switch -F129-

z

Vehicles with air conditioner only, otherwise blind plug

6. Coolant pipe

z

Coolant hose connection diagram, See COOLANT HOSE CONNECTION DIAGRAM

7. Retaining clip

z

Check if seated securely

8. 10 N.m

9. To bottom of expansion tank

z

Coolant hose connection diagram, See COOLANT HOSE CONNECTION DIAGRAM

10. To top of radiator

z

Coolant hose connection diagram, See COOLANT HOSE CONNECTION DIAGRAM

11. O-ring

z

Replace

12. Connecting unions

13. To bottom of radiator

z

Coolant hose connection diagram, See COOLANT HOSE CONNECTION DIAGRAM

14. Oil cooler

z

Removing and installing, See PART II (OIL FILTER HOUSING, DISASSEMBLING AND

NOTE:

Coolant hose connection diagram, See COOLANT HOSE CONNECTION
DIAGRAM

NOTE:

The following list refers to items in Fig. 3 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)



ASSEMBLING) .

15. 15 N.m

16. Coolant thermostat

z

Checking: Heat up thermostat in water

z

Starts to open: approx. 86°C

z

Opening stroke: min. 7 mm

z

Removing and installing, See THERMOSTAT, REMOVING AND INSTALLING

17. Toothed belt

z

Mark direction of rotation before removing

z

Check for wear

z

Do not kink

z

Removing, installing and tensioning. See TOOTHED BELTS, REMOVING, INSTALLING
AND TENSIONING
 .

18. Coolant pump

z

Check for ease of movement

z

If damaged or leaking replace complete

z

Removing and installing, See COOLANT PUMP, REMOVING AND INSTALLING

19. Rear toothed belt guard

20. 20 N.m

21. Throttle valve control module

z

Heated by coolant

z

Coolant hose connection diagram, See COOLANT HOSE CONNECTION DIAGRAM

22. To top of expansion tank

z

Coolant hose connection diagram, See COOLANT HOSE CONNECTION DIAGRAM

23. O-ring

z

Replace if damaged



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)
