5. Engine Coolant Temperature (ECT) sensor -G62-

z

Checking:

See On Board Diagnostic (OBD)

z

With Engine Coolant Temperature (ECT) sensor -G2-

6. 4 N.m (35 in. lb)

7. Cap

z

Check using VAG1274 tester and VAG 1274/8 adapter

z

Test pressure 1.4 to 1.6 bar

8. 2 N.m (18 in. lb)

9. Coolant expansion tank

z

Perform cooling system leak check using VAG 1274 tester with VAG 1274/9 adapter

10. Connector

11. To cylinder head

z

Coolant hose connections, diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

12. Air ducting

13. 10 N.m (7 ft lb)

14. Additional fan

z

Optional equipment

15. Fan ring

z

For auxiliary fan

16. Retaining clip

z

Make sure it is seated securely

17. Fan ring

18. Coolant fan

19. Bracket

z

For coolant fan connector

20. Coolant hose, lower

z

Attached to radiator with clip

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

21. Coolant fan control (FC) thermal switch -F18-

z

35 N.m (26 ft lb)

z

For electric fan

Switching temperatures:

z

Stage 1 ON: 92 to 97° C OFF: 84 to 91° C



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle



z

Stage 2 ON: 99 to 105° C OFF: 91 to 98° C

22. Bracket

z

For radiator

23. Bracket

z

For radiator

z

Note installation position

Fig. 1: Exploded View Of Cooling System Components (Body Side)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

COOLING SYSTEM COMPONENTS, ENGINE SIDE

1. 25 N.m (18 ft lb)

2. Coolant pump

z

Check arm for ease of movement

z

Note installation position

z

Removing and installing: See COOLANT PUMP, REMOVING AND INSTALLING .

z

If damaged and leaking replace complete assembly

3. O-ring

z

Always replace

4. EGR cooler

5. To expansion tank

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

6. Coolant hose, upper

z

Coolant hose connections, diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

7. To cylinder head

NOTE:

The following list refers to items in Fig. 2 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle



z

Coolant hose connections, diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

8. To heat exchanger

z

Coolant hose connections, diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

9. From heat exchanger

z

Coolant hose connections, diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

10. Coolant pipe

z

Coolant hose connections, diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

11. 10 N.m (7 ft lb)

12. To expansion tank, lower

z

Coolant hose connections, diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

13. EGR cooler supply

z

Coolant hose connections, diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

14. Connection

z

With glow plugs -Q7- for auxiliary heater

15. To top of radiator

z

Coolant hose connections, diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

z

Clipped to bulkhead

16. O-ring

z

Make sure it is seated securely

z

Always replace

17. To bottom of radiator

z

Coolant hose connections, diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

18. Connection

z

For thermostat

19. Coolant thermostat

z

Removing and installing. See THERMOSTAT, REMOVING AND INSTALLING .

z

Observe installed position. See THERMOSTAT, REMOVING AND INSTALLING .

z

Checking: heat-up thermostat in water

z

Opening starts at 85° C approx.

z

Ends approx. 105° C

z

Opening lift 7 mm minimum

20. Oil cooler

z

Removing and installing: See PART II (item -3-)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle



Fig. 2: Exploded View Of Cooling System (Engine Side)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

COOLANT HOSE CONNECTIONS, DIAGRAM

1. Radiator

2. Oil cooler

3. Coolant pump

4. Engine block

5. Expansion tank

6. Intake manifold

7. EGR cooler

8. Heating system heat exchanger

9. Coolant pipe

10. Transmission cooler

z

Vehicles with automatic transmission

11. Coolant hose, upper

12. Coolant hose, lower

NOTE:

The following list refers to items in Fig. 3 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle
