z

Remove retaining clamp(s) from refrigerant lines.

z

Secure radiator to body before removing lock carrier.

z

Remove condenser from radiator and secure to lock carrier.

COOLANT FAN, CHECKING

Engine codes AEG, AVH, AZG

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

V.A.G 1594 Adapter set

z

Wiring diagram

Fig. 17: Identifying Special Tool
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirements

z

Main fuses must be OK

z

Coolant Fan Control (FC) thermal switch -F18- OK



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)



Fig. 18: Locating Main Fuses (Left Front Corner Of Engine Compartment)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Work sequence

z

Remove left side sound insulation:

See NOISE INSULATION, ASSEMBLY OVERVIEW .

z

Disconnect 3-pin connector from Coolant Fan Control (FC) thermal switch -F18-.

z

Bridge contact -1- and contact -2- of connector with auxiliary cables from V.A.G 1594 A.

Connector type A

Fig. 19: Identifying Coolant Fan Connector Type A
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Connector type B



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)



Fig. 20: Identifying Coolant Fan Connector Type B
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Connector type C

Fig. 21: Identifying Coolant Fan Connector Type C
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1st speed for Coolant fan -V7- and Right coolant fan -V35- must start

z

Switch on ignition.

z

Bridge contact -2- and contact -3- of connector with auxiliary cables from V.A.G 1594 A.

2nd speed for Coolant fan -V7- and Right coolant fan -V35- must start.

If 1st or 2nd speeds of fans do not run:

z

Locate and eliminate open circuit using wiring diagram:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)



See appropriate SYSTEM WIRING DIAGRAMS article.

If no wiring fault is detected:

z

Replace Coolant fan -V7- or Right coolant fan -V35-.

COOLANT PUMP, REMOVING AND INSTALLING

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

T10007 Refractometer

z

V.A.G 1306 Drip tray

z

V.A.G 1331 Torque wrench (5...50 N.m)

z

VAS 5024 Assembly tool for spring-type clamps

Fig. 22: Identifying Special Tools
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Drain coolant, See COOLING SYSTEM, DRAINING AND FILLING .

z

Remove ribbed belt, See RIBBED BELT, REMOVING AND INSTALLING .

z

Remove tensioning element for ribbed belt.

NOTE:

z

Always replace seals and gaskets.

z

The lower section of the toothed belt guard need not be removed.

z

The toothed belt should be left in position on the crankshaft pulley.

z

Cover the toothed belt with a cloth to protect it from coolant before
removing the coolant pump.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)
