Volkswagen New Beetle. Manual - part 932





Fig. 3: Identifying Coolant Hose Connections (Coolant Flow Diagram)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

COOLING SYSTEM, DRAINING AND FILLING

Special tools and equipment

z

VAG 1306 Drip tray for VAG1202A

Fig. 4: Identifying Vag 1306 Drip Tray For Vag1202A
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAG 1921 Hose clip pliers

z

Anti-freeze tester



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle



Fig. 5: Identifying VAG 1921 Hose Clip Pliers
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Draining

z

Remove engine cover.

z

Remove cap from coolant expansion tank.

z

Remove insulation tray center and left:

See PLENUM CHAMBER SEALING ASSEMBLY, REMOVING AND INSTALLING .

z

Unscrew drain plug to drain coolant from radiator (arrow).

Fig. 6: Locating Radiator Drain Plug
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

To drain coolant from engine also remove coolant hose from oil cooler (arrow).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle



Fig. 7: Removing Coolant Hose From Oil Cooler
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Filling

NOTE:

Observe proper disposal regulations!

NOTE:

z

Only use coolant additive G 12 in accordance with TL VW 774 D.
Identification: red colored.

z

On no account must G 12 be mixed with other coolant additives!



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle



RECOMMENDED COOLANT MIXTURE RATIOS

z

Close drain plug for coolant.

z

Fill with coolant up to MAX. mark on expansion tank.

z

If the fluid in expansion tank is brown, G 12 has been mixed with other
coolant. In this case the coolant must be changed.

z

G 12 and coolant additives marked "In accordance with TL VW 774 D"
prevent frost and corrosion damage, scaling and also raise boiling point of
coolant. For this reason the system must be filled all year round with frost
and corrosion protection additives.

z

Particularly in countries with tropical climates, the coolant due to the
higher boiling point improves engine reliability when heavily loaded.

z

Protected against frost to about -25° C (in arctic climatic countries to
about -35° C).

z

The coolant concentration must not be reduced by adding water even in
warmer seasons and in warmer countries. The anti-freeze ratio must be at
least 40%.

z

Use clean drinking water when mixing the coolant.

z

If for climatic reasons a greater frost protection is required, the amount of
G 12 can be increased, but only up to 60% (frost protection to about -40°
C), as otherwise frost protection is reduced again and cooling
effectiveness is also reduced.

z

If radiator, heat exchanger, cylinder head or cylinder head gasket is
replaced, do not reuse old coolant.

Frost protection to:

Antifreeze amount

G 12

(1)

Water

(1)

-25° C
-35° C

40%
50%

2.4 ltr.
3.0 ltr.

3.6 ltr.
3.0 ltr.

(1)

The quantity of coolant can vary depending upon the vehicle equipment.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle
