Fig. 5: Identifying VAG 1921 Hose Clip Pliers Draining z Remove engine cover. z Remove cap from coolant expansion tank. z Remove insulation tray center and left: See PLENUM CHAMBER SEALING ASSEMBLY, REMOVING AND INSTALLING . z Unscrew drain plug to drain coolant from radiator (arrow). Fig. 6: Locating Radiator Drain Plug z To drain coolant from engine also remove coolant hose from oil cooler (arrow).
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle
|
