Volkswagen New Beetle. Manual - part 916





Fig. 24: Installing Coolant Pump
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing toothed belt and adjusting timing. See TOOTHED BELTS, REMOVING, INSTALLING
AND TENSIONING
 .

z

Install ribbed belt tensioning element and torque to 25 N.m.

z

Install ribbed belt. See RIBBED BELT, REMOVING AND INSTALLING .

z

Fill with coolant, See COOLING SYSTEM, DRAINING AND FILLING .

THERMOSTAT, REMOVING AND INSTALLING

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

T10007 Refractometer

z

V.A.G 1306 Drip tray

z

V.A.G 1331 Torque wrench (5-50 N.m)

z

VAS 5024 Assembly tool for spring-type clamps

Fig. 25: Identifying Special Tools
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Drain coolant, See COOLING SYSTEM, DRAINING AND FILLING .

z

Pull coolant hose off union -3-. See Fig. 26 .

z

Remove securing bolts -4- of union -3- and remove union -3- with thermostat -1-.

NOTE:

Always replace seals and gaskets.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)



Fig. 26: Removing And Installing Thermostat
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Installation is performed in the reverse sequence. Note the following:

z

Moisten new O-ring -2- with coolant. See Fig. 26 .

z

Fit union -3- with thermostat -1- onto engine block.

z

Tighten securing bolts -4- to 15 N.m.

z

Fill with coolant, See COOLING SYSTEM, DRAINING AND FILLING .

NOTE:

The brace on the thermostat must be almost vertical.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)



1998-2004 ENGINE

Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle

COOLING SYSTEM COMPONENTS, REMOVING AND INSTALLING

GENERAL INFORMATION

Perform cooling system leakage test with VAG 1274 cooling system tester and 1274/9 adapter.

Cooling system components, body side. See COOLING SYSTEM COMPONENTS, BODY SIDE .

Cooling system components, engine side. See COOLING SYSTEM COMPONENTS, ENGINE SIDE .

Coolant hose connections, diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

Engine coolant, draining and filling. See COOLING SYSTEM, DRAINING AND FILLING .

Engine coolant, mixture ratios. See RADIATOR, REMOVING AND INSTALLING .

COOLING SYSTEM COMPONENTS, BODY SIDE

1. Radiator

z

Removing and installing. See RADIATOR, REMOVING AND INSTALLING

z

After replacing, replace entire engine coolant

2. O-ring

z

Always replace

3. Coolant hose, upper

z

Attached to radiator with clip

z

Coolant hose connections, diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM

4. Retaining clip

NOTE:

z

As the engine warms up, cooling system pressure also increases. If
necessary, release pressure before starting repair work.

z

Hoses are secured with spring clips. When performing repairs, only use
spring clips.

z

VAG 1921 pliers are recommended for installing spring clips.

z

When installing coolant hoses, route them stress-free, so they do not
come into contact with other components (observe markings on coolant
connections and hoses).

NOTE:

The following list refers to items in Fig. 1 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle



z

Make sure it is securely seated

5. Engine Coolant Temperature (ECT) sensor -G62-

z

Checking:

See On Board Diagnostic (OBD)

z

With Engine Coolant Temperature (ECT) sensor -G2-

6. 4 N.m (35 in. lb)

7. Cap

z

Check using VAG1274 tester and VAG 1274/8 adapter

z

Test pressure 1.4 to 1.6 bar

8. 2 N.m (18 in. lb)

9. Coolant expansion tank

z

Perform cooling system leak check using VAG 1274 tester with VAG 1274/9 adapter

10. Connector

11. To cylinder head

z

Coolant hose connections, diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

12. Air ducting

13. 10 N.m (7 ft lb)

14. Additional fan

z

Optional equipment

15. Fan ring

z

For auxiliary fan

16. Retaining clip

z

Make sure it is seated securely

17. Fan ring

18. Coolant fan

19. Bracket

z

For coolant fan connector

20. Coolant hose, lower

z

Attached to radiator with clip

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTIONS, DIAGRAM .

21. Coolant fan control (FC) thermal switch -F18-

z

35 N.m (26 ft lb)

z

For electric fan

Switching temperatures:

z

Stage 1 ON: 92 to 97° C OFF: 84 to 91° C



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle
