Volkswagen New Beetle. Manual - part 915





Fig. 18: Locating Main Fuses (Left Front Corner Of Engine Compartment)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Work sequence

z

Remove left side sound insulation:

See NOISE INSULATION, ASSEMBLY OVERVIEW .

z

Disconnect 3-pin connector from Coolant Fan Control (FC) thermal switch -F18-.

z

Bridge contact -1- and contact -2- of connector with auxiliary cables from V.A.G 1594 A.

Connector type A

Fig. 19: Identifying Coolant Fan Connector Type A
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Connector type B



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)



Fig. 20: Identifying Coolant Fan Connector Type B
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Connector type C

Fig. 21: Identifying Coolant Fan Connector Type C
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1st speed for Coolant fan -V7- and Right coolant fan -V35- must start

z

Switch on ignition.

z

Bridge contact -2- and contact -3- of connector with auxiliary cables from V.A.G 1594 A.

2nd speed for Coolant fan -V7- and Right coolant fan -V35- must start.

If 1st or 2nd speeds of fans do not run:

z

Locate and eliminate open circuit using wiring diagram:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)



See appropriate SYSTEM WIRING DIAGRAMS article.

If no wiring fault is detected:

z

Replace Coolant fan -V7- or Right coolant fan -V35-.

COOLANT PUMP, REMOVING AND INSTALLING

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

T10007 Refractometer

z

V.A.G 1306 Drip tray

z

V.A.G 1331 Torque wrench (5...50 N.m)

z

VAS 5024 Assembly tool for spring-type clamps

Fig. 22: Identifying Special Tools
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Drain coolant, See COOLING SYSTEM, DRAINING AND FILLING .

z

Remove ribbed belt, See RIBBED BELT, REMOVING AND INSTALLING .

z

Remove tensioning element for ribbed belt.

NOTE:

z

Always replace seals and gaskets.

z

The lower section of the toothed belt guard need not be removed.

z

The toothed belt should be left in position on the crankshaft pulley.

z

Cover the toothed belt with a cloth to protect it from coolant before
removing the coolant pump.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)



z

Remove upper and center sections of toothed belt guard.

z

Take toothed (timing) belt off coolant pump toothed belt pulley. See TOOTHED BELTS,
REMOVING, INSTALLING AND TENSIONING
 .

z

Unscrew securing bolt -1- for rear toothed belt guard -2-. See Fig. 23 .

z

Unscrew securing bolts -5- for coolant pump and remove coolant pump -4-.

Fig. 23: Removing Coolant Pump
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Installation is performed in the reverse sequence. Note the following:

z

Moisten new O-ring -3- with coolant. See Fig. 24 .

z

Install coolant pump -4-. Installation position: Coolant pump sealing plug faces downward.

z

Tighten securing bolts -5- to 15 N.m.

z

Tighten securing bolt -1- for rear toothed belt guard -2- on cylinder head to 20 N.m



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)
