Volkswagen New Beetle. Manual - part 919





Fig. 9: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Drain coolant. See COOLING SYSTEM, DRAINING AND FILLING .

z

Remove front panel:

See PLENUM CHAMBER SEALING ASSEMBLY, REMOVING AND INSTALLING .

z

Disconnect coolant hoses from radiator.

z

Disconnect connectors from thermo-switch.

z

Remove ribbed belt tensioner. See RIBBED BELT TENSIONER, REMOVING AND
INSTALLING
 .

z

Remove radiator mounting bolts and take out radiator.

Installing

Installation is carried out in the reverse order of the removal procedure. Note the following during installation:

Engine coolant, filling. See COOLING SYSTEM, DRAINING AND FILLING .

A/C SYSTEM, ADDITIONAL REMOVAL INFORMATION

NOTE:

Vehicles with A/C:

z

Observe additional information and removal work. See A/C SYSTEM,
ADDITIONAL REMOVAL INFORMATION .

WARNING:

Do NOT open the A/C refrigerant circuit.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle



z

Remove retaining clamp(s) from refrigerant lines.

z

Before removing lock support, fasten radiator to body

z

To remove radiator, fasten condenser to the body.

COOLANT PUMP, REMOVING AND INSTALLING

Special tools and equipment

z

VAG 1306 Drip tray forVAG1202A

z

VAG 1331 Torque wrench: 5 to 50 N.m (3.7 to 37 ft lb)

z

VAG 1921 Hose clip pliers

z

Anti-freeze tester

Fig. 10: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Drain coolant. See COOLING SYSTEM, DRAINING AND FILLING .

z

Remove ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING .

z

Disconnect fuel supply and return lines at fuel filter.

NOTE:

To prevent damage to the condenser and to the refrigerant lines/hoses, make
sure that the lines and hoses are not stretched, kinked or bent.

NOTE:

z

Always replace seals and gaskets.

z

Lower part of the toothed belt guard need not be removed.

z

Toothed belt should be left in position on the crankshaft sprocket.

z

Cover toothed belt with a cloth to protect it from coolant before removing
coolant pump.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle



z

Remove connector hose between charge air cooler and intake manifold. See CHARGE AIR COOLER
COMPONENTS, REMOVING AND INSTALLING
 .

z

Remove fuel filter with bracket. See FUEL FILTER, SERVICING .

z

Remove belt guard upper and middle sections. See PART II .

z

Remove V-belt from camshaft sprocket, injection pump sprocket and coolant pump sprocket. See
TOOTHED BELTS, REMOVING, INSTALLING, TENSIONING .

z

Unscrew mounting bolt -1- from pulley -2- and press downward approx. 30 mm.

Fig. 11: Removing Mounting Bolt From Pulley
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unscrew mounting bolts -3- from coolant pump and carefully remove coolant pump -4- between engine
bracket and toothed belt guard.

Installing

Installation is carried out in the reverse order of the removal procedure. Note the following during installation:

z

Moisten new O-ring -3- with clean engine coolant.

z

Insert coolant pump -4- into engine block and tighten mounting bolts -5- to 15 N.m (11 ft lb).

z

Install pulley -2- and tighten mounting bolt -1- (replace). Tightening torque: 40 N.m (30 ft lb) plus
additional 90° (1/4 turn).

z

Install and tighten toothed belt. See TOOTHED BELTS, REMOVING, INSTALLING,
TENSIONING
 .

z

Install fuel filter with bracket.

z

Disconnect fuel supply and return lines at fuel filter.

z

Install ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING

NOTE:

Coolant pump plug points downward.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle



z

Install connecting hose between charge air cooler and intake hose. See CHARGE AIR COOLER
COMPONENTS, REMOVING AND INSTALLING
 .

z

Fill engine with coolant. See COOLING SYSTEM, DRAINING AND FILLING .

THERMOSTAT, REMOVING AND INSTALLING

Special tools and equipment

z

VAG 1306 Drip tray for VAG1202A

z

VAG 1331 Torque wrench: 5 to 50 N.m (3.7 to 37 ft lb)

z

VAG 1921 Hose clip pliers

z

Anti-freeze tester

Fig. 12: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Drain coolant. See COOLING SYSTEM, DRAINING AND FILLING .

z

Remove coolant hose from connection -2-

z

Unscrew mounting bolts -1- of connection -2- and remove connection -2- along with thermostat -4-.

z

Turn thermostat -4- 1/4 turn. (90°)to the left and remove from connection -2-.

NOTE:

Always replace seals and gaskets.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle
