If the wheels do not lock, there is a malfunction in the hydraulic part of the ABS system. In this case the See CONTROL MODULE AND HYDRAULIC UNIT, REMOVING AND INSTALLING . z Press --> key. The ABS warning light -K47- goes out. Indicated on display The final control diagnosis is completed z Press --> key. Fig. 237: V.A.G 1551 Scan Tool Display - Initiating On Board Diagnosis Test Mode (34 Of 35) Indicated on display z There is a malfunction in the system if the ABS warning light -K47- does not go out. z Adhere exactly to test sequence: First check DTC memory, then erase. z End output (Function 06), see DIAGNOSTIC TROUBLE CODE (DTC) ERASING MEMORY,
2003 Volkswagen New Beetle GLS 1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle
|
