Fig. 229: V.A.G 1551 Scan Tool Display - Initiating On Board Diagnosis Test Mode (26 Of 35) Indicated on display z Indicate to 2nd mechanic which wheel requires turning by hand. Fig. 230: V.A.G 1551 Scan Tool Display - Initiating On Board Diagnosis Test Mode (27 Of 35) z Press --> key. Indicated on display z Press --> key. ABS hydraulic pump -V64- must run. Brake pedal must not give If the brake pedal gives, there is a malfunction in the hydraulic unit. In this case the hydraulic unit must be See NOTE: If the wheel does not lock, there is a possibility that there is a malfunction
2003 Volkswagen New Beetle GLS 1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle
|
