Volkswagen New Beetle. Manual - part 752





Fig. 36: Displaying Control Module Identification Number
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

System designation (ABS 20 IE)

z

Data BUS present. (CAN)

z

Control module code (03504).

Coding control module, see CODE CONTROL MODULE (FUNCTION 07) .

z

Workshop code: See operating instructions for Vehicle Diagnosis, Testing and Information System VAS
5051

Indicated on display

Select diagnostic function:

At this point all diagnostic functions are available.

For further measures see repair procedures.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



Fig. 37: Selecting Diagnostic Function
Courtesy of VOLKSWAGEN OF AMERICA, INC.

DIAGNOSTIC TROUBLE CODE (DTC) TABLE

NOTE:

z

When beginning troubleshooting of the vehicle control modules, always
start with "Automatic Test Sequence" address word 00 by pressing
buttons -0- and -0-, because the control modules are interconnected with a
CAN-bus wire. This checks DTC memory of the control modules in the
vehicle.

z

All the possible malfunctions which can be recognized by ABS control
module (w/EDL) -J104- and printed-out on VAG1551 are listed on the
following pages according to the 5 digit DTC.

z

DTC appears (in the "Rapid data transfer" mode) only on the print-out.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



DIAGNOSTIC TROUBLE CODE (DTC) - ITT MARK 20 IE (1 OF 20)

Example:

DTC Malfunction code

5 digit 3 digit

00283 035

z

The 3 digit malfunction code next to the DTC can be disregarded, but the
text describing the malfunction type is relevant.

z

Reference is made to individual "Electrical testing" test steps in the
"Corrective action" column.

z

Before replacing components indicated as being faulty, check all the
appropriate harness connectors, wiring and Ground (GND) connections
using the wiring diagram.

z

After carrying out repairs, always check and erase DTC memory with the
VAG1551 scan tool. Road test at a speed exceeding 20 km/h (13 mph).

z

After the road test, check DTC memory again.

V.A.G
1551
print-
out

Possible cause

Corrective action

00283





Front
left
speed
sensor
-G47-

z

Open circuit, short to positive or

Ground, or loose contact in

connections between left front ABS

wheel speed sensor -G47- and ABS

control module (w/EDL) -J104

z

Check wiring and connections using wiring

diagram

z

Perform electrical checks, see

ELECTRICAL TESTING



z

Damaged rotor or speed sensor -

G47

z

Speed sensor windings -G47- faulty

z

Check left front ABS wheel speed sensor -

G47- and rotor for damage

z

Replace rotor/speed sensor -G47-





See ABS SYSTEM COMPONENTS FOR

FRONT AXLE, REMOVING AND

INSTALLING ;ABS SYSTEM COMPONENTS

ON REAR AXLE, REMOVING





If the malfunction occurs again:



z

ABS control module (w/EDL) -

J104- faulty

z

Replace ABS control module (w/EDL) -

J104-





See ABS CONTROL MODULE AND

HYDRAULIC UNIT, REMOVING AND

INSTALLING ; HYDRAULIC UNIT, BRAKE



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



DIAGNOSTIC TROUBLE CODE (DTC) - ITT MARK 20 IE (2 OF 20)

DIAGNOSTIC TROUBLE CODE (DTC) - ITT MARK 20 IE (3 OF 20)

BOOSTER/MASTER CYLINDER -

ASSEMBLY OVERVIEW .

V.A.G 1551
print-out

Possible cause

Corrective action

00283





Front left
speed sensor
-G47
Signal
outside
tolerances

(1)

z

Open circuit, short to positive or

Ground, or loose contact in

connections between left front

ABS wheel speed sensor -G47 and

ABS control module (w/EDL) -

J104-

z

Check wiring and connections using

wiring diagram

z

Perform electrical checks, see

ELECTRICAL TESTING



z

Electrical interference from other

sources (high frequency radiation

e.g. non-insulated ignition cable)

z

Read measured value block, see READ

MEASURING VALUE BLOCK

(FUNCTION 08) Display group number

001



z

Damaged rotor or speed sensor -

G47





z

Excessive air gap between left

front ABS wheel speed sensor -
G47- and rotor (signal not OK.)

z

Check left front ABS wheel speed sensor -

G47- and rotor for damage

z

Replace rotor/speed sensor





See ABS SYSTEM COMPONENTS FOR

FRONT AXLE, REMOVING AND

INSTALLING or ABS SYSTEM

COMPONENTS ON REAR AXLE,

REMOVING AND INSTALLING .

(1)

Type of DTC, this DTC is only recognized above 20 km/h (13 MPH) (carry out test drive).

V.A.G 1551
print-out

Possible cause

Corrective action

00283





Front left
speed sensor
-G47
Mechanical
malfunction

(1)

z

Excessive air gap

between left front ABS

wheel speed sensor -

G47- and rotor (signal

not OK.)

z

Check installation of left front ABS wheel speed

sensor -G47- and rotor

See ABS SYSTEM COMPONENTS FOR

FRONT AXLE, REMOVING AND

INSTALLING or ABS SYSTEM

COMPONENTS ON REAR AXLE,

REMOVING AND INSTALLING .

z

Read measured value block, see READ
