Volkswagen New Beetle. Manual - part 710





1C0 907 379 ABS/EDL/ASR/ESP for vehicles up to my 09.00

1C0 907 379 E/G/M ABS/EDL/ASR/ESP for vehicles from my 10.00

Trouble Code (DTC) memory

A non-volatile memory ensures that the contents of the DTC memory are retained even without a voltage
supply.

Data output

Data output is transmitted with V.A.G 1551 scan tool in operating mode 1 (Rapid data transfer), and with tester
VAS 5051 in operating mode vehicle OBD.

SAFETY PRECAUTIONS AND FUNDAMENTAL POINTS REGARDING TROUBLESHOOTING

TROUBLESHOOTING WITH V.A.G 1551 SCAN TOOL OR TESTER VAS 5051 ON ABS MARK 60
(FLOW CHART)

NOTE:

z

The ABS is a vehicle safety system; the appropriate knowledge is
necessary to work on the system.

z

In order to check complaints and to be able to carry out pin-pointed
troubleshooting, the Diagnostic Trouble Code DTC memory must be
checked before commencing work on the ABS system.

z

Only separate connectors when the ignition is switched off.

z

Observe the appropriate instructions regarding the handling of brake fluid.

z

ABS malfunctions are indicated by the ABS warning light illuminating.
Certain malfunctions will only be recognized at speeds above 20 km/h
(approx. 13 mph) (carry out road test).

z

If the ABS warning light -K47- and the Warning light for brake system -
K118- warning lights do not illuminate, but the brake system is not
functioning correctly then the malfunction must be sought in the
conventional braking system. See DISC .



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



Fig. 148: Troubleshooting With V.A.G 1551 Scan Tool Or Tester VAS 5051 On ABS Mark 60 - Flow
Chart (1 Of 2)

Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



Fig. 149: Troubleshooting With V.A.G 1551 Scan Tool Or Tester VAS 5051 On ABS Mark 60 - Flow
Chart (2 Of 2)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

ELECTRICAL/ELECTRONIC COMPONENTS AND INSTALLING LOCATIONS

1. ABS hydraulic unit -N55-

z

Located on left of engine compartment.

z

The ABS hydraulic pump -V64- and the inlet/outlet valves in the hydraulic unit are checked by On
Board Diagnostic (OBD)

z

The ABS hydraulic pump -V64- and valve block must NOT be separated from one another

z

Removing and installing

See HYDRAULIC UNIT, BRAKE BOOSTER/BRAKE MASTER CYLINDER ASSEMBLY
OVERVIEW MARK 60
 ; CONTROL MODULE AND HYDRAULIC UNIT, REMOVING
AND INSTALLING
 .

z

When changing the hydraulic unit, always seal the old part with the plugs from the repair set Part
No. 1 H0 698 311 A

NOTE:

The following list refers to items in Fig. 150 .



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



2. ABS Control Module (w/EDL) -J104-

z

Location: on hydraulic unit on left of engine compartment

z

Checked by On Board Diagnostic (OBD)

z

Checking the multi-pin connector to control module, see MULTI-PIN CONNECTOR WITH
CONTACT ASSIGNMENTS


z

Do not disconnect multi-pin connector before successfully completing OBD. Switch ignition off
before separating connection.

z

Removing and installing

See HYDRAULIC UNIT, BRAKE BOOSTER/BRAKE MASTER CYLINDER ASSEMBLY
OVERVIEW MARK 60
 ; CONTROL MODULE AND HYDRAULIC UNIT, REMOVING
AND INSTALLING
 .

Vehicles with ABS/ESP only

z

When the ABS Control Module (w/EDL)-J104- is replaced, a zero compensation must be
performed

z

Initiate basic settings, see INITIATING BASIC SETTING Perform display group numbers 060,
063 and 066

3. Brake light switch -F-

z

The brake light switch is open in the rest position;

z

Adjusting, see ADJUSTING BRAKE LIGHT SWITCH

z

Can be checked via read measured value block, see MEASURED VALUE BLOCK, READING

4. Sender for rotation rate -G202-

z

Vehicles with ABS/EDL/ASR/ESP only

z

Location: Under instrument panel next to steering column

z

Checked by OBD

z

Can be checked via read measured value block, see MEASURED VALUE BLOCK,
READING


z

Observe installation instructions

See ESP SYSTEM COMPONENTS, REMOVING AND INSTALLING .

5. Sensor for transverse acceleration -G200-

z

Vehicles with ABS/EDL/ASR/ESP only

z

Location: Under instrument panel next to steering column

z

Checked by OBD

z

Can be checked via read measured value block, see MEASURED VALUE BLOCK,
READING


z

Observe installation instructions
