FUNCTIONAL CHECK: ESP CONTROL LAMP -K155 BRAKE LIGHT SWITCH, ADJUSTING Vehicle up to m.y. 02.00 See BRAKE LIGHT SWITCH . z Remove driver's side storage compartment. z Pull harness connector off brake light switch. z Remove brake light switch by turning 90° clockwise. z Pull brake light switch plunger fully out. z Press brake pedal down as far as possible by hand. z Guide brake light switch through assembly opening and reinstall by turning 90° to left. z Release brake pedal. instrument cluster
z Reconnect connectors to both front speed sensors again z Check DTC memory and erase
Functional check: ESP Control lamp -K155 Test V.A.G 1598 sockets Item tested z Test conditions z Additional operations Specified value Corrective action 22 - Function of ASR/ESP control lamp - K155- z Switch ignition on ASR/ESP control lamp -K155- lights up for 2 seconds and goes out again
z Check wiring using wiring diagram
z Malfunction in instrument cluster NOTE: Remove brake light switch to adjust.
2003 Volkswagen New Beetle GLS 1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle
|
