Volkswagen New Beetle. Manual - part 686





Fig. 33: Identifying VAS 5051 Vehicle Diagnosis, Testing And Information System
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

With ignition switched off, connect tester VAS 5051 to diagnosis connection using diagnosis cable VAS
5051/1 or VAS 5051/3.

Indicated on display

Select operating mode:

NOTE:

z

The ABS function is switched off in the control module during the On
Board Diagnostic.

z

The DTC memory can be erased after successful checking and repair.

NOTE:

z

In the functions 04 - Basic setting/08 - Read Measured value block,
the display zones will be listed from top to bottom.

z

If the display does not indicate as described in the work sequence,
operating instructions for Vehicle Diagnosis, Testing and Information
System VAS 5051.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



z

Press button on display for "Vehicle On Board Diagnostic" -arrow-.

Fig. 34: Pressing Button On Display For "Vehicle On Board Diagnostic"
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Indicated on display

Select vehicle system:

z

Press "03 - Brake electronics" on display -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



Fig. 35: Pressing "03 - Brake Electronics" On Display
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Displayed is

z

The control module identification number.

e.g. (1J0 907 379 D)

Application of control module: See Parts catalog



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



Fig. 36: Displaying Control Module Identification Number
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

System designation (ABS 20 IE)

z

Data BUS present. (CAN)

z

Control module code (03504).

Coding control module, see CODE CONTROL MODULE (FUNCTION 07) .

z

Workshop code: See operating instructions for Vehicle Diagnosis, Testing and Information System VAS
5051

Indicated on display

Select diagnostic function:

At this point all diagnostic functions are available.

For further measures see repair procedures.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle
