Fig. 37: Selecting Diagnostic Function
Courtesy of VOLKSWAGEN OF AMERICA, INC.

DIAGNOSTIC TROUBLE CODE (DTC) TABLE

NOTE:

z

When beginning troubleshooting of the vehicle control modules, always
start with "Automatic Test Sequence" address word 00 by pressing
buttons -0- and -0-, because the control modules are interconnected with a
CAN-bus wire. This checks DTC memory of the control modules in the
vehicle.

z

All the possible malfunctions which can be recognized by ABS control
module (w/EDL) -J104- and printed-out on VAG1551 are listed on the
following pages according to the 5 digit DTC.

z

DTC appears (in the "Rapid data transfer" mode) only on the print-out.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



DIAGNOSTIC TROUBLE CODE (DTC) - ITT MARK 20 IE (1 OF 20)

Example:

DTC Malfunction code

5 digit 3 digit

00283 035

z

The 3 digit malfunction code next to the DTC can be disregarded, but the
text describing the malfunction type is relevant.

z

Reference is made to individual "Electrical testing" test steps in the
"Corrective action" column.

z

Before replacing components indicated as being faulty, check all the
appropriate harness connectors, wiring and Ground (GND) connections
using the wiring diagram.

z

After carrying out repairs, always check and erase DTC memory with the
VAG1551 scan tool. Road test at a speed exceeding 20 km/h (13 mph).

z

After the road test, check DTC memory again.

V.A.G
1551
print-
out

Possible cause

Corrective action

00283





Front
left
speed
sensor
-G47-

z

Open circuit, short to positive or

Ground, or loose contact in

connections between left front ABS

wheel speed sensor -G47- and ABS

control module (w/EDL) -J104

z

Check wiring and connections using wiring

diagram

z

Perform electrical checks, see

ELECTRICAL TESTING



z

Damaged rotor or speed sensor -

G47

z

Speed sensor windings -G47- faulty

z

Check left front ABS wheel speed sensor -

G47- and rotor for damage

z

Replace rotor/speed sensor -G47-





See ABS SYSTEM COMPONENTS FOR

FRONT AXLE, REMOVING AND

INSTALLING ;ABS SYSTEM COMPONENTS

ON REAR AXLE, REMOVING





If the malfunction occurs again:



z

ABS control module (w/EDL) -

J104- faulty

z

Replace ABS control module (w/EDL) -

J104-





See ABS CONTROL MODULE AND

HYDRAULIC UNIT, REMOVING AND

INSTALLING ; HYDRAULIC UNIT, BRAKE



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



DIAGNOSTIC TROUBLE CODE (DTC) - ITT MARK 20 IE (2 OF 20)

DIAGNOSTIC TROUBLE CODE (DTC) - ITT MARK 20 IE (3 OF 20)

BOOSTER/MASTER CYLINDER -

ASSEMBLY OVERVIEW .

V.A.G 1551
print-out

Possible cause

Corrective action

00283





Front left
speed sensor
-G47
Signal
outside
tolerances

(1)

z

Open circuit, short to positive or

Ground, or loose contact in

connections between left front

ABS wheel speed sensor -G47 and

ABS control module (w/EDL) -

J104-

z

Check wiring and connections using

wiring diagram

z

Perform electrical checks, see

ELECTRICAL TESTING



z

Electrical interference from other

sources (high frequency radiation

e.g. non-insulated ignition cable)

z

Read measured value block, see READ

MEASURING VALUE BLOCK

(FUNCTION 08) Display group number

001



z

Damaged rotor or speed sensor -

G47





z

Excessive air gap between left

front ABS wheel speed sensor -
G47- and rotor (signal not OK.)

z

Check left front ABS wheel speed sensor -

G47- and rotor for damage

z

Replace rotor/speed sensor





See ABS SYSTEM COMPONENTS FOR

FRONT AXLE, REMOVING AND

INSTALLING or ABS SYSTEM

COMPONENTS ON REAR AXLE,

REMOVING AND INSTALLING .

(1)

Type of DTC, this DTC is only recognized above 20 km/h (13 MPH) (carry out test drive).

V.A.G 1551
print-out

Possible cause

Corrective action

00283





Front left
speed sensor
-G47
Mechanical
malfunction

(1)

z

Excessive air gap

between left front ABS

wheel speed sensor -

G47- and rotor (signal

not OK.)

z

Check installation of left front ABS wheel speed

sensor -G47- and rotor

See ABS SYSTEM COMPONENTS FOR

FRONT AXLE, REMOVING AND

INSTALLING or ABS SYSTEM

COMPONENTS ON REAR AXLE,

REMOVING AND INSTALLING .

z

Read measured value block, see READ



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



DIAGNOSTIC TROUBLE CODE (DTC) - ITT MARK 20 IE (4 OF 20)

DIAGNOSTIC TROUBLE CODE (DTC) - ITT MARK 20 IE (5 OF 20)

MEASURING VALUE BLOCK (FUNCTION

08) Display group number 002

z

Perform output Diagnostic Test Mode (DTM), see

OUTPUT DIAGNOSTIC TEST MODE

(FUNCTION 03)





If the malfunction occurs again:



z

Outlet valve in ABS

hydraulic unit -N55-

faulty

z

Replace ABS hydraulic unit -N55-





See ABS CONTROL MODULE AND HYDRAULIC

UNIT, REMOVING AND INSTALLING

HYDRAULIC UNIT, BRAKE BOOSTER/MASTER

CYLINDER - ASSEMBLY OVERVIEW .

(1)

Type of DTC, this DTC is only recognized above 20 km/h (13 MPH) (carry out test drive).

VAG1551 Scan
Tool display

Possible cause

Corrective action

00000
No DTC recognized If "No DTC recognized" appears after carrying out repairs, On Board Diagnostic

(OBD) is ended.



If, despite "No DTC recognized" appearing on the display, ABS system does not
operate properly, proceed as follows:



z

Road test at speed exceeding 20 km/h (13 mph).



z

If there is still no DTC stored, check DTC memory again.



z

Continue troubleshooting without On Board Diagnostic (OBD) and perform
the complete Electrical testing, see ELECTRICAL TESTING .

V.A.G
1551
printout

Possible cause

Corrective action

00285
Front right
speed
sensor
-G45

z

Open circuit, short to positive or

Ground, or loose contact in
connections between speed

sensor -G45- and ABS control

module (w/EDL) -J104-

z

Check wiring and connections using wiring

diagram

z

Perform electrical checks, see

ELECTRICAL TESTING



z

Damaged rotor or Right front

ABS wheel speed sensor -G45

z

Right front ABS wheel speed

sensor -G45- faulty

z

Check Right front ABS wheel speed sensor -

G45- and rotor for damage

z

Replace rotor/Right front ABS wheel speed

sensor -G45-
