Fig. 4: ABS & ABS/EDL Troubleshooting Flow Chart V.A.G 1551 Scan Tool / Tester VAS 5051 (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.


Fig. 5: ABS & ABS/EDL Troubleshooting Flow Chart V.A.G 1551 Scan Tool / Tester VAS 5051 (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.


ELECTRICAL/ELECTRONIC COMPONENTS AND INSTALLATION LOCATIONS

1. ABS hydraulic unit -N55-

The hydraulic unit consists of the following components:

z

ABS hydraulic pump -V64-

1

 )



z

Valve block (contains the inlet and outlet valves)

z

ABS hydraulic pump -V64- and valve block must not be separated from one another. See ANTI-
LOCK BRAKE SYSTEM
 .

NOTE:

The following list refers to items in Fig. 6 .



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



z

When changing hydraulic unit, always seal old part with plugs from repair set Part No. 1H0 698
311 A

z

Multi-pin harness connector terminal assignment, see MULTI-PIN HARNESS CONNECTOR
WITH TERMINAL ASSIGNMENT


2. ABS control module -J104-

z

Checked by On Board Diagnostic (OBD)

z

Located on hydraulic unit in left side of engine compartment

z

Removing and installing

See ABS CONTROL MODULE AND HYDRAULIC UNIT, REMOVING AND
INSTALLING
 .

z

Checking multi-pin harness connector to control module, see MULTI-PIN HARNESS
CONNECTOR WITH TERMINAL ASSIGNMENT


z

Before disconnecting harness connector:

„

Check DTC memory.

„

Switch ignition off before separating harness connector.

3. ABS/EDL hydraulic unit -N55-

The hydraulic unit consists of the components:

z

ABS hydraulic pump -V64-

1

 )



z

Valve block (contains the inlet and outlet valves)

z

ABS hydraulic pump -V64- and valve block must not be separated from one another.

z

When changing hydraulic unit, always seal old part with plugs from repair kit Part No. 1H0 698
311 A

z

Multi-pin harness connector terminal assignment, see MULTI-PIN HARNESS CONNECTOR
WITH TERMINAL ASSIGNMENT


4. ABS/EDL and ABS/EDL/ASR control module -J104-

z

Checked by On Board Diagnostic (OBD)

z

Located on hydraulic unit in left side of engine compartment

z

Checking multi-pin harness connector to control module, see MULTI-PIN HARNESS
CONNECTOR WITH TERMINAL ASSIGNMENT

CAUTION: Part numbers are listed here for reference only. Always check

with your Parts department for the latest information.

CAUTION: Part numbers are listed here for reference only. Always check

with your Parts department for the latest information.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



z

Before disconnecting harness connector:

„

Check DTC memory.

„

Switch ignition off before separating harness connector.

5. Brake light switch -F-

z

Open in rest position

z

Adjusting, see BRAKE LIGHT SWITCH, ADJUSTING

z

Can be checked via Read Measuring Value Block, see READ MEASURING VALUE BLOCK
(FUNCTION 08)


6. Data Link Connector (DLC)

z

Installation position: Current model (DLC) location is left of steering column, under the instrument
panel. Early production is at the center console below heating/air conditioning controls.

7. ASR/ESP Control Lamp -K155- (only for vehicles with ASR)

z

Location: In instrument cluster

8. Warning light for brake system -K118-

z

Location: in instrument cluster

z

Function, see PARKING BRAKE INDICATOR LIGHT -K14-/WARNING LIGHT FOR
BRAKE SYSTEM -K118-


9. ABS warning light -K47-

z

Location: in instrument cluster

z

Function, see WARNING LIGHTS

10. ABS wheel speed sensors -G45-/-G47- (front)

z

Checked by On Board Diagnostic (OBD)

z

Before inserting sensor clean inner surface of sensor mounting and coat with lubricating paste G
000 650

z

When connecting wheel speed sensor wire make sure it is not twisted in wheelhousing

z

Securing bolt tightening torque: 10 N.m (7 ft lb)

11. Wheel hub with wheel speed sensors rotor (front)

z

Removing and installing

See SUSPENSION - FRONT (GOLF/JETTA/GTI FROM LATE 1999 PRODUCTION) .

12. ABS wheel speed sensor -G44-/-G46- (rear)

z

Checked by On Board Diagnostic (OBD)

z

Installing, see item 10

13. Wheel hub with wheel speed sensor rotor (rear)

z

Removing and installing

See SUSPENSION - FRONT (GOLF/JETTA/GTI FROM LATE 1999 PRODUCTION) .



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



Fig. 6: Identifying Electrical/Electronic Components And Installation Locations (ITT Mark 20 IE)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

DIAGNOSTIC TROUBLE CODES (DTC) DISPLAYED BY WARNING LIGHTS -K14-, -K47- AND -
K118-

Warning lights

WARNING LIGHTS CHART

For vehicles with ABS/EDL/ASR and/or a radio/navigation system, the warning light for brake system -K118-
is at position -3-. See Fig. 7 . The function of the parking brake warning light -K14- is then taken on by the
warning light for brake system -K118-.

Fig. 7: Identifying Warning Light For K14, K47 And K118

Item

Designation

1

Warning light for brake system -K118-

2

ABS warning light -K47-

3

Parking brake indicator light -K14-
