Volkswagen New Beetle. Manual - part 663





z

Insert wheel speed sensor into hole in wheel bearing housing and tighten bolt to 8 N.m (71 in. lb).

z

Connect wheel speed sensor to speed sensor wiring.

z

Turn wheels fully to left and right lock and check clearance of speed sensor wiring.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 16: Disconnecting Connector For Front Wheel Speed Sensor And Speed Sensor Wiring
Courtesy of VOLKSWAGEN OF AMERICA, INC.


ABS wheel speed sensor gap, checking

z

Raise vehicle.

z

Remove wheel.

z

Rotate brake disc and check whether wheel speed sensor rotor is damaged or dirty.

z

If rotor is damaged, remove wheel hub with rotor and replace

See WHEEL BEARING (WHEEL BEARING HOUSING INSTALLED IN VEHICLE) .

Rotor runout, checking

z

Raise vehicle.

z

Remove wheel.

z

Turn wheel hub and measure distance between rotor and speed sensor, dimension -a-, all around.

z

dimension -a- = 0.3 mm (0.0118 in.)

z

If rotor is not true, remove wheel hub with rotor and replace.

See WHEEL BEARING (WHEEL BEARING HOUSING INSTALLED IN VEHICLE) .



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 17: Measuring Distance Between Rotor And Speed Sensor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

FRONT WHEEL SPEED SENSOR WIRING, REMOVING AND INSTALLING

Special tools and equipment

z

VAS 1978 wiring repair kit

Removing:

z

Obtain radio code on vehicles with coded radio.

z

Disconnect battery.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 18: Identifying VAS 1978 Wiring Repair Kit
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle
