Pull off intake hose -1- and connector -2- from Mass Air Flow (MAF) sensor.

z

Remove bolts -4- and -5-.

z

Remove air cleaner unit.

Fig. 19: Pulling Off Intake Hose And Connector From Mass Air Flow Sensor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove connector from ABS Control Module (arrow -1-) and pull off (arrow -2-).



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 20: Removing Connector From ABS Control Module
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Using a screwdriver, lift cover of multi-pin connector and remove.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 21: Lifting Cover Of Multi-Pin Connector Using A Screwdriver
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Using a small screw driver, push purple latch in direction of arrow.

Pin assignment of harness connector T25 and ABS Control Module (w/EDL) -J104-



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 22: Pushing Purple Latch Using A Small Screw Driver
Courtesy of VOLKSWAGEN OF AMERICA, INC.

HARNESS CONNECTOR T25 PIN REFERENCE - FRONT WHEEL SPEED SENSORS

Pin

Connected to component:

19 + 20

Right Front ABS Wheel Speed Sensor -G45-

1 +2

Left Front ABS Wheel Speed Sensor -G47-
