z

Remove bolts -4- and -5-.

z

Remove air cleaner as complete unit.

z

For vehicles with Diesel engines, remove relay panel above brake booster.

z

Remove as much brake fluid as possible from brake fluid reservoir using a bleeder bottle.

z

Install brake pedal depressor from VAG 1238 B or equivalent.

z

Connect bleeder bottle hose to left front brake caliper bleeder screw and open bleeder screw. Close
bleeder screw.

z

Release control module connector (arrow -1-) and disconnect (arrow -2-).

WARNING:

z

Brake fluid is poisonous.

z

To draw off brake fluid from the reservoir use a bleeder bottle
used only for brake fluid. Never siphon brake fluid by mouth.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 10: Releasing Control Module Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Place plastic covering under control module and hydraulic unit. Do not use rags.

Observe safety precautions; see SAFETY PRECAUTIONS .

z

Disconnect brake lines from hydraulic unit to brake master cylinder (arrows) and suspend with wire.

Fig. 11: Disconnecting Brake Lines From Hydraulic Unit To Brake Master Cylinder And Suspend
With Wire

Courtesy of VOLKSWAGEN OF AMERICA, INC.

CAUTION: Do not let brake fluid enter electrical connectors.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



z

Disconnect remaining brake lines on hydraulic unit.

z

Seal brake lines and threaded holes (arrows) with plugs from repair kit, Part No. 1H0 698 311 A.

z

Remove bolts on hydraulic unit bracket (arrows).

Fig. 12: Removing Bolts On Hydraulic Unit Bracket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove hydraulic unit with control module.

ABS control module, removing from hydraulic unit

z

Disconnect electrical connector for hydraulic pump motor from control module.

z

Remove bolts (arrows) from control module.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 13: Removing Bolts From Control Module
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull control module straight up to remove.

NOTE:

z

Be sure that the hydraulic unit valve dome is not tilted against the control
module solenoid valves.

z

Cover the control module magnetic coils with a plastic covering. Do not
use rags.

z

After separating the control module and hydraulic unit, use transportation
protection for the valve dome.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle
