Volkswagen New Beetle. Manual - part 659





11. ABS control module

12. Brake line connection

z

Hydraulic unit to left front brake caliper

13. Brake line connection

z

Hydraulic unit to right rear wheel cylinder/caliper

14. Brake line connection

z

Hydraulic unit to left rear wheel cylinder/caliper

15. Brake line connection

z

Hydraulic unit to right front brake caliper

16. Brake line

z

Brake master cylinder/primary piston circuit to hydraulic unit

17. Brake line

z

Master brake cylinder/secondary piston circuit to hydraulic unit

18. Self-locking nut

z

20 N.m (15 ft. lb)

z

Always replace

19. Heat shield

z

Only for vehicles with 110 kW engine

20. Self-locking nut

z

20 N.m (15 ft. lb)

z

Always replace

21. Seal

z

Always replace

22. Seal

23. Vacuum hose

{

Insert into brake booster

24. Gasket

z

For brake booster

25. Self-locking nut

z

20 N.m (15 ft. lb)

z

Always replace

26. Boot

z

Be sure boot is properly seated.

27. Bracket



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 4: Identifying Hydraulic Unit, Brake Booster/Master Cylinder Component - ITT Mark 20 IE
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



BRAKE LINES FROM BRAKE MASTER CYLINDER TO HYDRAULIC UNIT, CONNECTING

A. A - Secondary piston circuit

B. B - Primary piston circuit

Fig. 5: Identifying Vehicles With ABS - ITT Mark 20 IE
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Hydraulic unit to right front brake caliper

NOTE:

The following list refers to items in Fig. 5 .



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



2. Hydraulic unit to left rear wheel cylinder/brake caliper

3. Hydraulic unit to right rear wheel cylinder/brake caliper

4. Hydraulic unit to left front brake caliper

A. Secondary piston circuit

B. Primary piston circuit

Fig. 6: Identifying Vehicles With ABS/EDL - ITT Mark 20 IE
Courtesy of VOLKSWAGEN OF AMERICA, INC.

ABS CONTROL MODULE AND HYDRAULIC UNIT, REMOVING AND INSTALLING

Special tools and equipment:

NOTE:

The following list refers to items in Fig. 6 .



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle
