VAG 1331 Torque wrench or equivalent

Fig. 7: Identifying VAG 1331 Torque wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAG 1410 Torque wrench or equivalent



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 8: Identifying VAG 1410 Torque Wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Location

The control module is attached to the hydraulic unit and is located on the left side of the engine compartment.

Removing

z

Obtain radio code for vehicles with coded radio.

z

Disconnect battery.

z

Remove intake hose -1- and connector -2- from Mass Air Flow (MAF) Sensor.

CAUTION: Before working on any part of the brake system, read CAUTIONS and

WARNINGS in SAFETY PRECAUTIONS
.

CAUTION: Do not bend brake lines at the hydraulic unit.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 9: Removing Intake Hose And Connector From Mass Air Flow Sensor
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle
