Volkswagen New Beetle. Manual - part 549





Fig. 113: Removing Oil Reservoir
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



z

Moisten O-ring -3- with hydraulic oil G 002 000 and insert into pump housing groove.

z

Moisten inside of oil reservoir, in area of O-ring with hydraulic oil.

z

To assemble, slide oil reservoir on with a turning motion and tighten using new Torx(R) screws -1-. (2
N.m).

Fig. 114: Installing Oil Reservoir
Courtesy of VOLKSWAGEN OF AMERICA, INC.

WARNING:

Always torque reservoir bolts to specification, otherwise oil
reservoir will be damaged.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



z

Install hydraulic pump, see HYDRAULIC PUMP, REMOVING AND INSTALLING .

z

Fill hydraulic system and bleed, see HYDRAULIC SYSTEM, FILLING AND BLEEDING .

HYDRAULIC CYLINDER, ASSEMBLY OVERVIEW

1. Hydraulic cylinder

2. Hydraulic hoses

3. Circlip

4. Hydraulic hoses

5. Retaining clip

6. Retainer

7. Pin

8. Bolt/screw

z

23 N.m

z

Qty. 2

9. Convertible Top Position Switch -F171-

z

Installed only on right-hand side.

10. Screwdriver

11. Ball head

12. Cover

13. Securing clip

14. Piston rod

WARNING:

The hydraulic system reacts with extreme sensitivity to all types of
contaminants. As soon as the system is opened the respective
component must be covered, to prevent dirt entering the hydraulic
system.

NOTE:

The following list refers to items in Fig. 115 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 115: Identifying Hydraulic Cylinder Assembly Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

HYDRAULIC CYLINDER, REMOVING AND INSTALLING

Removing

z

Open convertible top.

z

Remove side trim panel.

WARNING:

The hydraulic system reacts with extreme sensitivity to all types of
contaminants. As soon as the system is opened the respective
component must be covered, to prevent dirt entering the hydraulic
system.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
