Volkswagen New Beetle. Manual - part 547





Fig. 106: Disconnecting Electrical Connection From Convertible Top Hydraulic Pump -V118
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Loosen bypass valve -1- to release any residual pressure and then retighten.

z

Mark hydraulic lines -3- before removing. Undo Torx(R) screws -2- (7 N.m).

z

Pull hydraulic lines -3- carefully out from openings.

z

Remove combi-nut -4- (5 N.m).

Installing

Install in reverse order of removal.

HYDRAULIC PUMP IMPELLER, ASSEMBLY OVERVIEW

1. Hydraulic pump motor

z

Removing and installing, see Hydraulic pump, removing and installing .

2. Torx(R) screws

z

Always replace.

z

5 N.m.

3. Pump impeller

4. O-ring

z

Always replace.

z

O-ring is included in repair kit.

5. Hydraulic pump

NOTE:

z

Make sure hydraulic lines are installed in proper position on pump..

z

Make sure O-rings are not damaged and are seat correctly when installing
hydraulic lines.

z

Make sure there is no debris on pump in area of hydraulic line
connections.

z

After installing the hydraulic pump the system must be filled again and
bled., see HYDRAULIC SYSTEM, FILLING AND BLEEDING .

z

Reconnect battery, make sure the vehicle equipment (radio, clock, electric
windows) is checked as per Workshop manual and/or Owner's manual.

NOTE:

The following list refers to items in Fig. 107 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 107: Identifying Hydraulic Pump Impeller Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

HYDRAULIC PUMP IMPELLER, REMOVING AND INSTALLING

Removing

z

Remove hydraulic pump, see HYDRAULIC PUMP, REMOVING AND INSTALLING



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



z

Place hydraulic unit with reservoir facing downward vertically in a suitable container and secure it
against tipping.

z

Open bypass valve so that the hydraulic oil can flow from the pump unit into the container.

z

Remove Torx(R) screws -2- and pull motor -1- off hydraulic pump.

Fig. 108: Removing Hydraulic Pump Impeller
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull pump impeller -1- off drive shaft -2-.

NOTE:

z

Hydraulic system reacts with extreme sensitivity to all types of
contaminants.

z

Components must be covered immediately as the system is opened.

z

Place a suitable container under the pump to collect leaking oil before
dismantling the hydraulic unit.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



z

Remove metal tongue -3- from pump housing (Unit will be damaged if metal tongue remains in pump
housing).

Fig. 109: Removing Pump Impeller From Drive Shaft
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Metal tongue -3- is no longer required.

Installing

z

Press new pump impeller -1- onto drive shaft -2-

Pump impeller fits in one position only on drive shaft.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
