Volkswagen New Beetle. Manual - part 546





8. Hydraulic pump

z

Removing and installing, see HYDRAULIC PUMP, REMOVING AND INSTALLING .

9. Bypass valve

z

Unscrewing the bypass valve releases pressure in the hydraulic system and the convertible top can
be operated by hand.

10. Fluid level indicator

z

Hydraulic oil level must lie between min. and max. marks when convertible top is open.

11. Right Contact Switch (Cover Installed)-F156- or Left Contact Switch (Cover Installed) -F155- for

convertible top

z

Qty. 2.

12. Convertible Top Operation Switch -E137-

z

Installed in center console.

Fig. 103: Locating Electro/Hydraulic Convertible Top Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

HYDRAULIC SYSTEM, FILLING AND BLEEDING

If the hydraulic pump is overloaded, a thermal fuse breaks the current circuit and the system is switched off for
a maximum of 35 seconds. Then the system is fully functional again.

The bypass valve on the hydraulic cylinder is located behind a rubber cover behind the left luggage
compartment side panel trim. Turning the bypass valve counterclockwise releases pressure in the system and the
convertible top can be operated manually.

Filling hydraulic system

NOTE:

z

Electro/hydraulic convertible top is a closed hydraulic system. Filling is
normally only required after opening the hydraulic circuit (e.g. after
replacing a part).



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



z

Removing left-hand trim in luggage compartment

See LUGGAGE COMPARTMENT TRIM (CONVERTIBLE), REMOVING AND INSTALLING .

z

The convertible top must be open to fill the system as the actual level can only be determined in this
condition.

z

Remove oil filler plug -1-.

z

Oil for convertible top: G 002 000.

z

Top-off hydraulic oil until the oil level is between the min. and max. marks -2-.

z

An oil can is suitable for filling the hydraulic oil.

z

Oil can must only be used for this purpose, this prevents hydraulic oil being contaminated by other oils.

z

Tighten oil filler plug -1- (5 N.m).

Fig. 104: Removing Oil Filler Plug
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Bleeding hydraulic system

Hydraulic system is self-bleeding. System is bled by operating system several times.

z

Loosen oil filler plug -1-.

z

Switch ignition on and off again, keep ignition key in ignition lock.

z

For reasons of stroke and the displacing effect of the piston rod, the
hydraulic oil level must only be checked when the convertible top is open.

z

Observe safety instructions for electrical convertible top, see
CONVERTIBLE TOP .

WARNING:

Do not fill system above "max." mark, otherwise the pressure in the
system may be high enough to damage the system.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



z

Operate convertible top switch and open and close top 4 to 5 times.

z

System bleeds itself when opening and closing the convertible top several times.

z

Convertible top must open and close smoothly without juddering.

z

Oil level must be between min. and max. marks -2- when convertible top is open.

z

Tighten oil filler plug -1- (5 N.m).

Fig. 105: Installing Oil Filler Plug
Courtesy of VOLKSWAGEN OF AMERICA, INC.

HYDRAULIC PUMP, REMOVING AND INSTALLING

Removing

z

Disconnect the battery Ground (GND) strap observing all cautions. SeeBATTERY
DISCONNECTING/RECONNECTING PRECAUTIONS
 .

z

Removing left-hand trim in luggage compartment

See LUGGAGE COMPARTMENT TRIM (CONVERTIBLE), REMOVING AND INSTALLING .

z

Disconnect electrical connection from Convertible Top Hydraulic Pump -V118- -5-

WARNING:

z

The hydraulic system reacts with extreme sensitivity to all types of
contaminants.

z

As soon as the system is opened the respective component must be
covered, to prevent dirt entering the hydraulic system.

z

Before working on electrical system: Disconnect battery Ground
(GND) strap.

NOTE:

z

Obtain radio unit code before disconnecting battery.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
