Volkswagen New Beetle. Manual - part 544





Fig. 93: Removing Retaining Screw And Pulling Elastic Cable
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Install in reverse order of removal

HEADLINER, REMOVING AND INSTALLING.

Removing

z

Remove rivet -1-.

z

Remove retaining plate form rail by pushing it -arrow-.

z

Unclip retaining plate from convertible top -2- by pulling both pieces apart.

z

Untie knot at retaining plate and release cable by pulling it through guides -3-.

NOTE:

z

To ease installing procedure, a strong 3 feet long string can be tied to
the cable socket before introducing the retaining plate and fitting it to
the convertible top's fabric

z

After installing the retaining plate to the convertible top fabric and
attaching retaining plate to rail guide headlining, pull tied cable until
cable socket is reached

z

After screwing cable socket, cut the string.

NOTE:

To comfortably remove or repair headliners and to reach all needed pieces
open/close convertible top as needed (Use more or less a half open position).



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 94: Removing Retaining Plate Form Rail
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove three rivets -1- and release rail guide.

Fig. 95: Removing Rivets And Release Rail Guide
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove Roof leading edge trim.

See Convertible top front latch, assembly overview

z

Push retaining clips inside Convertible top fabric -arrows-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 96: Pushing Retaining Clips Inside Convertible Top Fabric
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unscrew retaining screw and pull wire -arrow-.

Fig. 97: Removing Retaining Screw And Pull Wire
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Install in reverse order of removal.

CONVERTIBLE TOP FRONT LATCH, ASSEMBLY OVERVIEW

1. Rods

z

Components 1, 2, 3 & 4 confirm the Front retaining catch, see CONVERTIBLE TOP,
ASSEMBLY OVERVIEW
 .

NOTE:

The following list refers to items in Fig. 98 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



2. Circlip

z

Components 1, 2, 3 & 4 confirm the Front retaining catch, see CONVERTIBLE TOP,
ASSEMBLY OVERVIEW
 .

3. Plate

z

Components 1, 2, 3 & 4 confirm the Front retaining catch, see CONVERTIBLE TOP,
ASSEMBLY OVERVIEW
 .

4. Bolt/screw

z

10 N.m

z

Components 1, 2, 3 & 4 confirm the Front retaining catch, see CONVERTIBLE TOP,
ASSEMBLY OVERVIEW
 .

5. Trim

z

Removing:

„

Remove circlip -6-

„

Remove pin -8-.

6. Circlip

7. Bolt/screw

z

10 N.m.

8. Pin

9. Hex socket head bolt/screw

10. Handle

z

Removing:

„

Remove Hex socket head bolt/screw from side.

11. Clip

12. Clip

13. Roof leading edge trim

z

Removing:

„

Unclip front and rear.

„

Turn through 90 and take off over handle -10-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
