Volkswagen New Beetle. Manual - part 542





Fig. 77: Removing Cable Sockets
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove guide rail headlining -4- from retaining plate in convertible top fabric -3-

z

Remove rail -2- from guide rail headlining -4- by sliding both pieces apart

Fig. 78: Removing Guide Rail Headlining From Retaining Plate In Convertible Top Fabric
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove rivet from frame -arrow- (seen from inside of the vehicle) and attached deflector with cable and
cable socket



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 79: Removing Rivet From Frame
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove previously removed cable with deflector and cable socket by passing it through fabric loops -
arrows-

Fig. 80: Removing Cable With Deflector And Cable Socket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Cut cable and pull it following direction of arrow, then dispose of it

NOTE:

Make sure that deflectors -1- are not damaged



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 81: Cutting Cable
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Untie knot -arrow- from new guide strip assembly

Fig. 82: Removing Knot From New Guide Strip Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove two plastic deflectors from cable and dispose of them

z

Pass cable (previously untied) through deflector at highest position -1- and then through deflector at
lowest position -2-



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 83: Passing Cable Through Deflector At Highest Position And Deflector At Lowest Position
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tie cable -arrow- (previously untied) into original position

Fig. 84: Installing Cable Into Original Position
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Clip guide rail headlining -4- to retaining plate inside convertible top fabric -3-

z

Slide rail -2- into guide rail headlining -4-

z

Make sure to pass cable -1- behind the rail

z

Make sure to pass cable -5- in front of rail

NOTE:

Illustration shows cable arrangement from outside of the vehicle. See Fig.
85 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
