Volkswagen New Beetle. Manual - part 541





Fig. 70: Pulling Convertible Top Lining Out Of Convertible Top Fabric Retaining Frame
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull beading out of insert channel of rear window -arrow-.

Fig. 71: Pulling Beading Out Of Insert Channel Of Rear Window
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove securing bolt from roof frame for convertible top lining rubber cable.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 72: Removing Securing Bolt From Roof Frame For Convertible Top Lining Rubber Cable
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull rubber cable out of loop on convertible top lining.

z

Remove screw securing convertible top elastic strap to convertible top retaining frame.

z

Drill out pop rivet for roof spoiler cassette beading -arrow-.

Fig. 73: Drilling Out Pop Rivet For Roof Spoiler Cassette Beading
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull beading out of roof spoiler cassette.

WARNING:

For security reasons, hold tension on elastic strap while removing
screw



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 74: Pulling Beading Out Of Roof Spoiler Cassette
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull slide -1- downward out of guide.

Installing

Install in reverse order of removal.

Fig. 75: Pulling Slide Downward Out Of Guide
Courtesy of VOLKSWAGEN OF AMERICA, INC.

HEADLINER TENSIONING SYSTEM, REMOVING AND INSTALLING

NOTE:

Stick convertible top lining bonding strip onto C-pillar using double-sided
adhesive tape.

NOTE:

z

To comfortably remove or repair headliner tensioning system, and to
reach all needed pieces open/close convertible top as needed (Use more



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



RAIL, REMOVING AND INSTALLING.

Removing

z

Remove three rivets -arrows- and release rail guide

Fig. 76: Removing Rail Guide
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove rail from convertible top frame and from guide rail headlining

Installing

z

Install in reverse order of removal

GUIDE RAIL HEADLINING, REMOVING AND INSTALLING.

Removing

z

Remove rail. See RAIL, REMOVING AND INSTALLING. .

z

Remove two rivets -1- and release cable sockets

or less a half open position)

z

Before opening or closing convertible top, observe that there is enough
room above convertible top to operate it

z

Each side of vehicle has a headliner tensioning system consisting of a rail,
a guide rail headlining (with attached cables, deflectors and cable sockets)
and a retaining plate (with attached elastic cable and cable socket)



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
