Volkswagen New Beetle. Manual - part 506





Fig. 43: Removing Screw From Glove Box
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove the 4 screws -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



z

Unclip trim -2- upward and remove from instrument panel.

Installing

Install in reverse order of removal.

Fig. 44: Installing Trim Screws
Courtesy of VOLKSWAGEN OF AMERICA, INC.

EYEGLASS COMPARTMENT, REMOVING AND INSTALLING

Eyeglass compartment above windshield (on roof liner - Sedan only)

z

Open eyeglass compartment and unclip cover 2- -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 45: Opening Eyeglass Compartment And Removing Cover (On Roof Liner Above Windshield -
Sedan Only)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull eyeglass compartment insert toward vehicle interior.

z

Remove screws -1- and -3-.

z

Take eyeglass compartment off roof liner.

Eyeglass compartment on driver's side (on roof liner - Sedan only)

z

Open eyeglass compartment -1- downward.

z

Pry cover -2- upward using a screwdriver and fold open.

z

Remove Phillips screws -3- and remove eyeglass compartment -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 46: Opening Eyeglass Compartment (On Roof Liner On Driver's Side - Sedan Only)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

FRONT ARMREST, REMOVING AND INSTALLING

Removing

z

Unclip trim -3- from center armrest -1-.

z

Remove screw -2- (18 N.m) and remove center armrest.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle
