Volkswagen New Beetle. Manual - part 507





Fig. 47: Removing Trim From Center Armrest
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

ARMREST LID, REMOVING AND INSTALLING

Removing

z

Open armrest lid -1-.

z

Press armrest lid -1- in direction of arrow B.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 48: Opening Armrest Lid
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Verify any existing damage of armrest lid base -A-.

z

Install in reverse order of removal.

SUN VISOR, REMOVING AND INSTALLING

Removing

z

Unhook sun visor -1- from mounting -2-.

z

Pry off cover caps -6-.

z

Remove screw -5-.

z

Release sun visor mounting -4- from mounting and separate connection -3-.

z

Pry off cover caps -7-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



z

Remove screws -8- and remove mounting -2-.

Fig. 49: Removing Sun Visor From Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

SUN VISOR (CONVERTIBLE), REMOVING AND INSTALLING

Removing

z

Unhook sun visor -1- from mounting -2-.

z

Pry off out cover caps -6-.

z

Remove screw -5-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



z

Release sun visor mounting -4- from mounting and separate connection -3-.

z

Pry off cover caps -7-.

z

Remove screws -8- and remove mounting -2-.

Fig. 50: Removing Sun Visor From Mounting (Convertible)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

Removing

z

Slide plenum chamber center cover -1- forward out of its locking device and take off of dash panel -
arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle
