z

Remove screw -1-.

z

Remove clip -2-.

Fig. 30: Removing Clip From Trim Under Center Of Instrument Panel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove screw -1-.

z

Pull trim -2- out to rear -arrow-.

Fig. 31: Removing Trim Under Center Of Instrument Panel Out To Rear
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull connector off for power socket if installed.

Installing

Install in reverse order of removal.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



GLOVE BOX, REMOVING AND INSTALLING

Removing

z

Release rear of cover -1- from instrument panel -3- and pull off instrument panel to rear.

Fig. 32: Removing Rear Of Cover From Instrument Panel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove bolts/screws -2-.

z

Pry off cover caps -1- and remove screws -2-.

z

Remove switch mounting -3- from retainer.

Fig. 33: Removing Switch Mounting From Retainer
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove screws -arrows- (Qty. 6) (screws in the center of the vehicle are hidden under cover caps).



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 34: Removing Glove Box Screws
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove glove box -1-.

z

Disconnect glove box lighting connections.

Installing

Install in reverse order of removal.

GLOVE BOX LOCK CYLINDER, REMOVING AND INSTALLING

z

In order to avoid damage, cover marked area of flaps -1- and -2-, e.g. with an adhesive tape.

z

Cover marked area of water pump pliers -3- with adhesive tape in order to avoid damage of the glove
box.

Fig. 35: Covering Marked Area Of Flaps With An Adhesive Tape
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Removing

z

Insert ignition key -1- in the lock cylinder -2-.

z

Press lock cylinder -in direction of -arrow-outward the handle -3- with water pump pliers.

Installing

z

Press lock cylinder into the handle opening until it audibly engages.

Fig. 36: Pressing Glove Box Lock Cylinder Into The Handle
Courtesy of VOLKSWAGEN OF AMERICA, INC.

GLOVE BOX LID, REMOVING AND INSTALLING

Removing

z

Remove glovebox. See GLOVE BOX, REMOVING AND INSTALLING .

z

Press plastic bolt from left side with pliers and remove in direction of -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle
