Volkswagen New Beetle. Manual - part 2540





Pry seal with a screw driver -A-. To do this, support the screw driver on the assembly tool 3253/2.

Fig. 158: Removing Right Flange Shaft Oil Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Seal and sleeve are driven out in one piece:

z

Pull out seal and sleeve at the same time.

NOTE:

z

Do not damage sleeve, otherwise leaks will occur.

z

Replace sleeve if damaged. See Pulling sleeve in .



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



The inner diameter of the sleeve has a pad.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 159: Removing Right Flange Shaft Oil Seal And Sleeve
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Install the puller hook VW 771/37 directly behind the pad in the sleeve.

z

Use force to press the puller hook VW 771/37 in the sleeve during the driving out sequence.

Installing

Seal and sleeve are driven out in two pieces:

z

Do not bend seal when driving new seal into sleeve onto stop.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
