Volkswagen New Beetle. Manual - part 2539





z

Insert flange shaft.

z

Install flange shaft with cone head bolt and tighten to prescribed torque. See REMOVING , item 18

z

Install drive shafts to transmission.

See FRONT AXLE SHAFT .

z

Top off transmission oil. See CHECKING FLUID LEVEL .

z

Install sound insulation trays.

Right flange shaft oil seal, removing

Special tools and equipment

Seal and sleeve are driven out in two pieces

z

3106 Drift

z

3253/2 Assembly tool

z

V.A.G1331 Torque wrench



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 155: Identifying Special Tools And Equipment (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

T10148 Press piece

z

3066 Assembly device

z

VW 771 Multipurpose tool

z

VW 771/37 Puller hooks

z

V.A.G1331 Torque wrench



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 156: Identifying Special Tools And Equipment (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove center and left noise insulation tray under engine/transmission if installed.

z

Turn steering to right onto full lock stop

z

Remove drive shaft protective cover from engine if installed

z

Disconnect drive shaft -1- from flange shaft.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 157: Disconnecting Right Drive Shaft From Right Flange Shaft
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tie-up drive shaft as high as possible. Do not damage paint on drive shaft.

z

Place container under transmission and engine.

z

Disconnect oil return line for turbocharger from engine, if installed (arrow).

See CHARGE AIR SYSTEM WITH TURBOCHARGER, TURBOCHARGER WITH
ATTACHMENTS, REMOVING AND INSTALLING

z

Remove flange shaft securing bolts by screwing two bolts into flange and counterhold flange shaft using
a lever.

z

Remove flange shaft with spring.

Seal and sleeve are driven out in two pieces:



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
