Volkswagen New Beetle. Manual - part 2499





Fig. 22: Removing Selector Shaft Out Of Transmission Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Transmissions as of 06.99

z

Remove selector shaft with selector mechanism cover; to do this place selector shaft in neutral position.
Then remove bolts -arrows- and pull selector shaft out of transmission housing.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 23: Removing Selector Shaft With Selector Mechanism Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continuation for all vehicles

z

Remove cover plate -A- and pivot pins -B- from underside of transmission.

Fig. 24: Removing Cover Plate And Pivot Pins From Underside Of Transmission
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



z

Remove pivot pins -A- on top side of transmission and transmission housing to clutch housing securing
bolts -B- in area of differential.

Fig. 25: Removing Top Side Of Transmission And Transmission Housing To Clutch Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove bolts -A-, from inside clutch housing for securing clutch housing to transmission housing.

NOTE:

Do not remove nuts -B- for output shaft bearing support.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 26: Removing Inside Clutch Housing For Securing Clutch Housing To Transmission Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Take off transmission housing, carefully pry up all round and alternating between sides on protruding
housing flange (arrows). Be careful not to damage sealing surfaces.

Fig. 27: Removing Protruding Housing Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove selector forks -A- together with selector plates.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
