A. Two arm puller e.g. Kukko 20/10 with Matra V/170 hooks.

B. Hex bolt M10 x 20

Fig. 18: Removing Synchro-Hub And 5th Gear Wheel With Needle Roller Bearing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull off 5th gear wheel

A. Two arm puller e.g. Kukko 20/10 with Matra V/170 hooks.

B. Hex bolt M10 x 20

Sequence for removing:

z

Install two arm puller and centralize by turning screw (arrow).

z

Heat gear wheel with hot air blower VAG 1416 and pull off.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 19: Removing 5th Gear Wheel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove both flange shafts.

NOTE:

When pulling off the gear wheel make sure that the hooks do not bend
outward, if necessary tighten screw (arrow). After 5th gear wheel has been
removed check for damage.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 20: Removing Flange Shafts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Take out flange shafts along with springs, thrust washers and tapered rings.

z

Remove both reverse shaft support bracket bolts (arrows).



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 21: Removing Reverse Shaft Support Bracket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Transmissions up to 05.99

z

Remove selector shaft with selector mechanism cover; to do this place selector shaft in neutral position.
Then remove bolts (arrows) and pull selector shaft out of transmission housing.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
