z

Remove transmission housing cover (arrow).



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 15: Removing Transmission Housing Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Remove 5th gear selector fork (arrow)

Fig. 16: Removing 5th Gear Selector Fork
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove spring for locking piece.

z

Remove locking collar and take off locking piece.

z

Slide locking collar, without selector fork, over synchro-hub again.

z

Remove bolts -A- for synchro-hub and 5th gear, to do this select 5th (arrow -1-) and 1st gear (arrows -2-
and -3-).



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 17: Removing Synchro-Hub And 5th Gear
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

After engaging both gears input shaft and output shaft are locked, synchro-hub and gear wheel cannot
turn. Both bolts can now be loosened.

z

Take off locking collar.

z

Pull off synchro-hub and 5th gear wheel and remove together with needle roller bearing.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
