Volkswagen New Beetle. Manual - part 2495





3. Gasket

4. 5Torx socket head bolt M10, 80 N.m

z

Install piece on bolt head holds saucer spring washer in position

5. Dished spring

z

Installing. See INSTALLATION POSITION OF DISHED SPRING FOR GEAR WHEEL
AND 5TH GEAR SYNCHRO-HUB SECURING BOLTS:


6. Socket head bolt, 25 N.m

z

For pivot pin to transmission housing

7. Pivot pin

8. 5th gear selector fork

z

Disassembling and assembling. See SELECTOR FORKS, DISASSEMBLING AND
ASSEMBLING


z

Adjusting. See ADJUSTING 5TH GEAR:

9. 5th gear locking collar

z

Installation position. See CHECKING 5TH GEAR SYNCHRO-RING

z

Adjusting. See ADJUSTING 5TH GEAR:

10. Synchro-hub with 5th gear and synchronizing ring

z

Disassembling and assembling. See 5th gear synchronizer

11. Needle roller bearing

12. 5th speed gear wheel

z

Installation position. See INSTALLATION POSITION 5TH GEAR WHEEL

NOTE:

If the transmission cover is installed with the transmission installed, check
oil level as follows:

z

Fill with oil to lower edge of filler hole and install filler plug.

z

Start engine, engage gear and allow transmission to turn for approx.
2 minutes.

z

Switch off engine and top off transmission oil to lower edge of filler
hole again.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 10: Exploded View Of Transmission Housing Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Transmission housing and selector mechanism, removing and installing

1. Cone head bolt, 25 N.m

2. Flange shaft with spring

z

Removing and installing. See ASSEMBLY SEQUENCE

z

Complement. See item 19 Flange Shaft

3. Torx socket head bolt, 30 N.m

z

For reverse shaft support

NOTE:

The following list refers to items in Fig. 11 .



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



z

Self-locking

z

Always replace

4. O-ring

z

Always replace

5. Pivot pin

6. Bolt, 25 N.m

7. Bolt, 25 N.m

8. Cover plate

9. Transmission housing

z

Servicing. See TRANSMISSION HOUSING AND CLUTCH HOUSING, SERVICING

10. Clutch housing

z

Servicing. See TRANSMISSION HOUSING AND CLUTCH HOUSING, SERVICING

11. Hex bolt, 25 N.m then turn 90° further

12. Selector mechanism

z

Disassembling and assembling on vehicles up to 05.99. See SELECTOR MECHANISM ON
TRANSMISSION SIDE, UP TO 05.99, DISASSEMBLING AND ASSEMBLING


z

Disassembling and assembling on vehicles as of 06.99. See SELECTOR MECHANISM ON
TRANSMISSION SIDE, AS OF 06.99, DISASSEMBLING AND ASSEMBLING


13. Hex bolt, 25 N.m



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 11: Exploded View Of Transmission Housing And Selector Mechanism
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Input shaft, output shaft (pinion shaft), differential and selector forks, removing and installing

1. Differential

z

Disassembling and assembling. See Differential, disassembling and assembling

2. Oil seal

z

Qty. 4

NOTE:

The following list refers to items in Fig. 12 .



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
