CALCULATING OVERALL RATIO "I"

Example:

CALCULATING OVERALL RATIO "i" (EXAMPLE)

i= Z

2

 "DIVIDE" Z

1

1

 )



I

G

 =Gear ratio = ZG

2

 / ZG

1

 =36 / 43 = 0.837



I

A

 = Final drive ratio = ZA

2

 / ZA

1

 = 72 / 17 = 4.235



i = Total ratio

= I

G

 x I

A

 = 0.837 x 4.235 = 3.545



1)

 Z

1

 = No. of teeth driving gear, Z

2

 = No. of teeth driven gear



GENERAL REPAIR INSTRUCTIONS

To ensure perfect transmission repairs, the greatest care and cleanliness as well as the use of good and proper
tools is essential. Obviously, the basis rules for safety are also applicable during repair work.

A number of generally valid instructions applicable for the various repair procedures - which were previously
repeated a number of times at numerous places in the Repair Manual - are summarized here. They apply to this
Repair Manual.

Transmission

z

When installing make sure that the dowel sleeves between the engine and transmission are correctly
located.

z

When changing a transmission fill with gear oil to the lower edge of the filler hole.

z

Capacities and specifications. See CODE LETTERS, TRANSMISSION APPLICATION, RATIOS,
CAPACITIES
 .

Gear

5th gear

Final drive

Driving gear

ZG

1

 = 43

ZA

1

 = 17

Driven gear

ZG

2

 = 36

ZA

2

 = 72

NOTE:

z

If the oil level is topped off with the transmission installed, carry out oil
level check as follows:



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Gaskets, sealing rings

z

Thoroughly clean joint surfaces and apply sealant AMV 188 200 03.

z

Apply sealant uniformly but not too thick.

z

Replace "O-rings".

z

Radial shaft oil seals.

Before installation:

z

Lightly oil outer edge, fill space between sealing lips -arrow-with grease G 052 128 A1.

z

Fill with oil to the lower edge of the filler hole and install filler plug. Start
the engine, engage a gear and allow transmission to turn for approx. 2
minutes. Switch off engine and again top off oil to lower edge of filler hole.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 6: Identifying Oil Seal Lip
Courtesy of VOLKSWAGEN OF AMERICA, INC.

After installation:

Check transmission oil; if necessary top-off to lower edge of oil filler hole, specification. See CODE
LETTERS, TRANSMISSION APPLICATION, RATIOS, CAPACITIES
 .

Locking devices



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



z

Replace circlips.

z

Do not overstretch circlips.

z

Circlips must be install properly in the groove.

z

Replace spring pins. Installation position: Slot longitudinal to line of force.

Fig. 7: Replacing Circlips
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Bolts and nuts

z

Tighten and loosen bolts and nuts for securing covers and housings in a diagonal sequence.

z

Delicate parts, must not be distorted, such as clutch pressure plates. Loosen and tighten nuts and bolts in



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
