Volkswagen New Beetle. Manual - part 2481





Fig. 156: Identifying Special Tools And Equipment (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove center and left noise insulation tray under engine/transmission if installed.

z

Turn steering to right onto full lock stop

z

Remove drive shaft protective cover from engine if installed

z

Disconnect drive shaft -1- from flange shaft.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 157: Disconnecting Right Drive Shaft From Right Flange Shaft
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tie-up drive shaft as high as possible. Do not damage paint on drive shaft.

z

Place container under transmission and engine.

z

Disconnect oil return line for turbocharger from engine, if installed (arrow).

See CHARGE AIR SYSTEM WITH TURBOCHARGER, TURBOCHARGER WITH
ATTACHMENTS, REMOVING AND INSTALLING

z

Remove flange shaft securing bolts by screwing two bolts into flange and counterhold flange shaft using
a lever.

z

Remove flange shaft with spring.

Seal and sleeve are driven out in two pieces:



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Pry seal with a screw driver -A-. To do this, support the screw driver on the assembly tool 3253/2.

Fig. 158: Removing Right Flange Shaft Oil Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Seal and sleeve are driven out in one piece:

z

Pull out seal and sleeve at the same time.

NOTE:

z

Do not damage sleeve, otherwise leaks will occur.

z

Replace sleeve if damaged. See Pulling sleeve in .



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



The inner diameter of the sleeve has a pad.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
