z

Remove flange shaft securing bolts by screwing two bolts into flange and counterhold flange shaft using
a lever.

z

Place container under transmission.

z

Remove flange shaft with spring.

z

Pull out seal for flange shaft with VW 771 and VW 771/37.

Fig. 153: Removing Left Oil Seal For Flange Shaft
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Drive new seal into sleeve onto stop, when doing this do not cant seal.

NOTE:

z

Do not damage sleeve, otherwise leaks will occur.

z

Replace sleeve if damaged. See Pulling sleeve in .



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 154: Installing Left Oil Seal Into Sleeve Onto Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Fill space between sealing lip and dust lip with sealing grease G052 128 A1.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



z

Insert flange shaft.

z

Install flange shaft with cone head bolt and tighten to prescribed torque. See REMOVING , item 18

z

Install drive shafts to transmission.

See FRONT AXLE SHAFT .

z

Top off transmission oil. See CHECKING FLUID LEVEL .

z

Install sound insulation trays.

Right flange shaft oil seal, removing

Special tools and equipment

Seal and sleeve are driven out in two pieces

z

3106 Drift

z

3253/2 Assembly tool

z

V.A.G1331 Torque wrench



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 155: Identifying Special Tools And Equipment (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

T10148 Press piece

z

3066 Assembly device

z

VW 771 Multipurpose tool

z

VW 771/37 Puller hooks

z

V.A.G1331 Torque wrench



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
