Fig. 140: Checking Synchro-Ring 1st Gear And Outer Ring For Wear
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Assembling locking collar and locking pieces with 1st and 2nd gear synchro-hub



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 141: Assembling Locking Collar And Locking Pieces With 1st And 2nd Gear Synchro-Hub
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



With introduction of the modified 1st gear synchronizer the shoulder has the same width on both sides of
synchro-hub.

The shoulder has a chamfer on one side (arrow B).

After assembly the shoulder of the synchro-hub and the outer splines of the locking collar (arrow A) face same
direction.

Recesses for locking pieces on synchro-hub and locking collar (arrow C) must align one over another.

Installation position of locking collar/synchro-hub 1st and 2nd gear

The locking collar splines (arrow) point to splines for 3rd/4th gear synchro-hub -A-.

z

Remove the 1st gear synchro-hub as described and install again.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 142: Identifying Installation Position Of Locking Collar/Synchro-Hub 1st And 2nd Gear
Courtesy of VOLKSWAGEN OF AMERICA, INC.

OUTPUT SHAFT, ADJUSTING

(Determining shim for output shaft)

Special tools and equipment

z

VW 387 Universal dial gauge bracket

z

VW 385/17 End measuring plate



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
