VW512 Press disk3114/2 Straightening tool

z

VW 407 Press tool

z

V.A.G1331 Torque wrench

z

Measuring dial gauge

Fig. 143: Identifying Special Tools And Equipment (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

1 - Kukko 21/6 Internal extractor

z

4 - Kukko 22/2 Retainer



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 144: Identifying Special Tools And Equipment (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

It is necessary to readjust the output shaft when the following components are replaced:

z

Final drive

z

Clutch housing

or

z

Tapered roller bearing

Adjustment overview. See Adjustment overview

z

Press small tapered roller bearing outer race together with a 0.65 mm thick shim into clutch housing. See
Output shaft, disassembling and assembling .

z

Insert output shaft and tighten nuts for bearing support to 25 N.m, then turn 90°.

z

Mount dial gauge (3 mm measuring range) and set to "0" with 1 mm preload.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 145: Mounting Dial Gauge With 1 mm Preload
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



z

Move output shaft up and down and note dial gauge reading (example: 0.30 mm).

Determining thickness of shim

The specified bearing preload is obtained by adding a constant preload figure of (0.20 mm) to the reading
obtained (0.30 mm) and the thickness of the shim installed (0.65 mm).

Example:

DETERMINING THICKNESS OF SHIM (EXAMPLE)

z

Remove output shaft and pull out small tapered roller bearing outer race. See Output shaft,
disassembling and assembling


The following adjustment shims are available:

SHIM THICKNESS SPECIFICATION (OUTPUT SHAFT)

Varying tolerances make it possible to obtain the exact shim thickness required.

z

Press in small tapered roller bearing outer race together with correct shim (See Output shaft,
disassembling and assembling
 ) and install output shaft. Tighten bearing support nuts in clutch housing

Shim installed

0.65 mm

+ Reading

0.30 mm

+ Preload (constant)

0.20 mm

Thickness of shim

1.15 mm

Size (mm)

Part No.

0.65

020 311 391 P

0.70

020 311 391 Q

0.75

020 311 391

0.80

020 311 391 A

0.85

020 311 391 B

0.90

020 311 391 C

0.95

020 311 391 D

1.00

020 311 391 E

1.05

020 311 391 F

1.10

020 311 391 G

1.15

020 311 391 H

1.20

020 311 391 J

1.25

020 311 391 K

1.30

020 311 391 L

1.35

020 311 391 M

1.40

020 311 391 N
