Volkswagen New Beetle. Manual - part 2459





z

3-Kukko 17/1 Separating device

Fig. 83: Identifying Special Tools And Equipment (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



1. Clutch housing

2. Tapered roller bearing outer race

z

Removing. See Pressing out tapered roller bearing outer race

z

Pressing in. See Pressing in tapered roller bearing outer race

3. Tapered roller bearing inner race

z

Pressing off. See Pressing off tapered roller bearing inner race .

z

Pressing on Pressing on tapered roller bearing inner race .

4. Input shaft

z

Adjusting. See INPUT SHAFT, ADJUSTING

5. 3rd gear wheel

z

Shoulder points to 4th gear

z

Pressing off. See Pressing off 4th gear wheel with tapered roller bearing and sleeve

z

Pressing on Pressing on 3rd gear wheel

6. Circlip

z

Always replace

7. 4th gear wheel

z

Press off with tapered roller bearing inner race and sleeve. See Pressing off 4th gear wheel with
tapered roller bearing and sleeve


z

Pressing on Pressing on 4th gear wheel

z

Collar faces to 3rd gear

8. Tapered roller bearing inner race

z

Pressing off with 4th gear wheel and sleeve. See Pressing off 4th gear wheel with tapered roller
bearing and sleeve


z

Pressing on Pressing on tapered roller bearing inner race

9. Thrust washer

10. Tapered roller bearing outer race

z

Pressing out Pressing out tapered roller bearing outer race

z

Pressing in. See Pressing in tapered roller bearing outer race

11. Shim

z

Determining thickness adjusting input shaft. See INPUT SHAFT, ADJUSTING

NOTE:

z

When installing new gear wheels, consult technical data. See Code letters,
transmission application, ratios, capacities .

z

If the position of the tapered roller bearings is affected when exchanging
parts, the input shaft must be readjusted. See adjustment overview. See
Adjustment overview .

NOTE:

The following list refers to items in Fig. 84 .



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



12. Transmission housing

13. Sleeve

z

For needle roller bearing

z

Press off with 4th gear wheel and tapered roller bearing inner race. See Pressing off 4th gear
wheel with tapered roller bearing and sleeve


z

Pressing on Pressing on tapered roller bearing inner race

z

Place thrust washer on before installing (item 9)

14. Needle roller bearing

15. 5th gear wheel

z

Pull off together with 5th gear synchro-hub. See Assembly sequence

16. 5th gear synchro-ring

z

With cast locking pieces. See 5th gear synchro-ring with cast locking pieces (arrows)

z

Check for wear. See Checking 5th gear synchro-ring

17. Spring

z

Installation position. See Assembling 5th gear locking collar/synchro-hub

z

From transmission manufacture date November 05 01 the spring was changed. See CHANGED
SPRINGS FOR 5TH GEAR SYNCHRONIZER FROM TRANSMISSION MANUFACTURE
DATE NOVEMBER 11 01


18. Lock pieces (Qty. 3)

z

Installation position. See 5th gear synchronizer

z

From transmission manufacture date March 05 01 are lock pieces installed, which are inner hollow

19. 5th gear synchro-hub

z

Removing and installing. See Assembly sequence

20. 5th gear locking collar

z

Removing and installing. See Assembly sequence

21. Dished washer

z

Installation position. See Installation position of dished spring for gear wheel and 5th gear
synchro-hub securing bolts:


22. Torx socket head bolt M 10, 80 N.m

z

Installed piece on bolt head locates dished spring. See Installation position of dished spring for
gear wheel and 5th gear synchro-hub securing bolts:



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 84: Disassembling Input Shaft Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pressing out tapered roller bearing outer race



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
