1. 1st and 2nd gear selector segments = 12.1 mm 1st and 2nd gear selector segments with changed synchronization = 11.4 mm. See Changed springs for The shorter selector segments can be installed in previous transmissions. 2. 3rd and 4th gear selector segments = 7.7 mm 3. 5th gear selector segments = 12.1 mm Removing circlip Fig. 76: Removing Circlip
2003 Volkswagen New Beetle GLS 1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
|
