Volkswagen New Beetle. Manual - part 2088





Fig. 42: Identifying Slide Rack Dimension
Courtesy of VOLKSWAGEN OF AMERICA, INC.


STEERING GEAR, ADJUSTING

z

Raise vehicle on hoist.

z

Wheels in straight-ahead position.

z

First technician: turn steering wheel back and forth (approx. 30° from center axis).

z

Knocking noise will be heard if there is excessive play

z

The second technician carefully turns the adjustment screw into the cover until the knocking noise can no
longer be heard inside the vehicle.

NOTE:

Two technicians are required when adjusting.

Adjust with engine switched off.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 43: Turning Steering Gear Adjustment Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Complete a road test ensuring that when maneuvering or negotiating corners the steering self-centers
without sticking.

z

Secure lock nut with a punch mark -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 44: Securing Steering Gear Adjustment Screw Lock Nut With Punch Mark
Courtesy of VOLKSWAGEN OF AMERICA, INC.

POWER STEERING PUMP, RESERVOIR, HYDRAULIC LINES

POWER STEERING PUMP DELIVERY PRESSURE, VEHICLES WITH POWER STEERING PUMP
IN LOWER SECTION, CHECKING

Special and equipment

z

3094 Hose clamps

z

V.A.G 1402 Power steering test unit

z

V.A.G 1402/1 A Adapter

z

V.A.G 1402/2 Adapter

z

V.A.G 1402/6 Hose from adapter set



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



z

VAS 5024 Assembly pliers

Fig. 45: Identifying Special Tool And Equipment



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle
