1. Hex on internally threaded shaft, wrench size 19 mm (.75 in.)

Dimension -a-; 94 +/- 0.5 mm (3.70 0.020 in.)

Identification "A" for right

B. B - Left-hand tie rod ball joint

1. Hex on internally threaded shaft, wrench size 19 mm (.75 in.)

Dimension -a-; 94 +/- 0.5 mm (3.70 0.020 in.)

Identification "B" for left

Identifying features for the previous tie rod ball joint



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 40: Identifying Features For The Previous Tie Rod Ball Joint (Flats For Wrench On Shaft)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Flats for wrench on the shaft, marked with "R" or "L"

wrench size 22 mm (.87 in.)

Dimension -a-; 74-1 mm (2.92 0.04 in.)

The shaft -arrow- is round

WARNING:

This tie rod ball joint must not be installed to a tie rod which has a length
of -a- 318.9 mm (12.56 in.)!



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



TIE RODS, MODIFIED

The tie rods have been shortened.

Tie rod dimensions

z

Previous tie rod; dimension -a- 343.1 mm (13.51 in.)

z

New tie rod; dimension -a- 318.9 mm (12.56 in.)

Fig. 41: Identifying Tie Rod Dimension Measuring Points
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

A mixed installation of previous and new tie rods is not allowed!



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



PLAY, SECURITY AND BOOTS ON TIE ROD ENDS, CHECKING

z

With vehicle raised (wheels hanging free), check play by moving tie rods and wheels.

z

Play: Zero play

z

Checking mountings.

z

Check boots are not damaged and are seated correctly.

CENTER POSITION ON STEERING RACK, DETERMINING

Steering rack should be positioned in the center before installing power steering gear.

z

Slide rack until dimension -a- is achieved.

Dimension -a- = 30.5 mm (1.20 in.)
