Volkswagen New Beetle. Manual - part 2086





Removing and installing power steering gear. See POWER STEERING, SERVICING

z

Seal line/hose connections on power steering gear if not already done.

z

Clean outside of power steering gear in surrounding area of the boot.

z

Open hose clamps and push boot back.

z

Clamp steering gear on transmission holder T10108 and unscrew tie rod from coupling rod.

z

To determine center position on the rack. See CENTER POSITION ON STEERING RACK,
DETERMINING


Fig. 37: Removing Tie Rod From Coupling Rod
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order.

Tightening torque:

NOTE:

To clamp steering gear, use hole "5" and the corresponding hole lying opposite
in transmission holder T10108.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Tie rod to power steering gear 75 N.m (55 ft lb)

Installing boot

z

Check boot for wear (cuts, cracks) and make sure sealing surfaces are clean.

z

Install boot, but first turn the tie rod so that the tie rod ball joint tapered pin is in the installation position.

z

Tighten clip with pliers V.A.G 1275.

Fig. 38: Tighten Boot Clamp Clip With Pliers V.A.G 1275
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install power steering gear.

NOTE:

z

Only use genuine clamp-type clips.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Removing and installing power steering gear. See POWER STEERING, SERVICING

TIE ROD BALL JOINTS, MODIFIED

The manufacturing process for the tie rod ball joints has been optimized. This has resulted in changes to the
external shape and length of the internally threaded shaft.

It was then necessary to modify the tie rods to match the tie rod ball joints. See TIE RODS, MODIFIED

Introduction will be gradual.

The modified tie rod ball joints can be recognized by the following features.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 39: Identifying Right And Left Hand Tie Rod Ball Joint
Courtesy of VOLKSWAGEN OF AMERICA, INC.

A. A - Right-hand tie rod ball joint



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle
