Fig. 77: Identifying Pressure Line And Suction Hose (2.0 ltr. Engine And A/C) Securing pressure line and suction hose on vehicles with unit injector TDI engine 1. Power steering pump z Checking delivery pressure. See POWER STEERING PUMP, RESERVOIR, HYDRAULIC z Before installing fill with oil Note. See POWER STEERING PUMP, RESERVOIR, 2. Banjo union bolt z 38 N.m (28 ft lb) 3. Sealing rings z Always replace 4. Pressure line 5. Spring-type clip 6. Sleeve z For power steering pumps from the company Kayaba only 7. Hex bolt z 22 N.m (16.2 ft lb) 8. Clamp 9. Suction hose 10. Cylinder block 11. Mounting bracket 12. Hex bolt z 40 N.m (30 ft lb) NOTE: The following list refers to items in Fig. 78 .
2003 Volkswagen New Beetle GLS 1998-2004 STEERING Steering - New Beetle
|
