Before installing fill with oil Note. See POWER STEERING PUMP, RESERVOIR,
HYDRAULIC LINES
 .

7. Pressure hose/line mounting

On automatic transmission 01M

Disassembling and assembling instructions. See SECURING PRESSURE LINE ON AUTOMATIC
TRANSMISSION 01M
 .

Fig. 73: Identifying Power Steering Pump With Hydraulic Lines/Hoses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Disassembling and assembling reservoir

1. Cap with dip stick

z

Oil level: between MIN. and MAX marks; Engine temperature approx. 50° C

z

Check oil level with cap bolt on

z

With engine cold, oil level must not rise above MIN. marking

z

Open cap with e.g. a bar

z

Arrow A: oil level with engine cold

2. Spring-type clip

3. Return hose

4. Suction hose

5. Bolt/screw ,

z

10 N.m (7.4 ft lb)

6. Reservoir

7. Battery console

NOTE:

The following list refers to items in Fig. 74 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 74: Disassembling And Assembling Power Steering Pump Reservoir
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Securing pressure line and suction hose on vehicles with TDI engine and A/C

1. Power steering pump

z

Checking delivery pressure. See POWER STEERING PUMP, RESERVOIR, HYDRAULIC
LINES
 .

z

Before installing fill with oil. See Note. See POWER STEERING PUMP, RESERVOIR,
HYDRAULIC LINES
 .

2. Suction hose

3. Spring-type clip

4. Pressure line

5. Banjo union bolt

z

38 N.m (28 ft lb)

6. Sealing rings

z

Always replace

7. Hex socket head bolt

z

40 N.m (30 ft lb)

8. Hex nut

z

22 N.m (16 ft lb)

9. Mounting bracket

10. Cylinder block

NOTE:

The following list refers to items in Fig. 75 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 75: Identifying Pressure Line And Suction Hose (Vehicles With 1.9L TDI Engine And A/C)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Securing pressure line and suction hose on vehicles with 2.0 ltr. & TDI engine without A/C and vehicles with 1.8 ltr.
turbo engine and A/C

1. Power steering pump

z

Checking delivery pressure. See POWER STEERING PUMP, RESERVOIR, HYDRAULIC
LINES


z

Before installing fill with oil, see Note. See POWER STEERING PUMP, RESERVOIR,
HYDRAULIC LINES


2. Suction hose

3. Spring-type clip

4. Pressure line

5. Banjo union bolt

z

38 N.m (28 ft lb)

6. Sealing rings

z

Always replace

7. Mounting bracket

8. Hex bolt

z

22 N.m (16 ft lb)

9. Hex bolt

z

40 N.m (30 ft lb)

10. Clamp

11. Mounting bracket

12. Cylinder block

NOTE:

The following list refers to items in Fig. 76 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 76: Identifying Pressure Line And Suction Hose (vehicles With 2.0 ltr. & 1.9L TDI Engine Without
A/C And Vehicles With 1.8 ltr. Turbo Engine And A/C)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Securing pressure line and suction hose on vehicles with 2.0 ltr. engine and A/C

1. Power steering pump

z

Checking delivery pressure. See POWER STEERING PUMP, RESERVOIR, HYDRAULIC
LINES


z

Before installing fill with oil. See Note. See POWER STEERING PUMP, RESERVOIR,
HYDRAULIC LINES


2. Suction hose

3. Spring-type clip

4. Pressure line

5. Banjo union bolt

z

38 N.m (28 ft lb)

6. Sealing rings

z

Always replace

7. Lock nut

8. Mounting bracket

9. Hex bolt

z

22 N.m (16 ft lb)

10. Hex bolt

z

40 N.m (30 ft lb)

11. Mounting bracket

12. Cylinder block

NOTE:

The following list refers to items in Fig. 77 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle
